Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 598.94 including GST
NZ$ 520.82 excluding GST
or four payments of $149.74
with
Learn More
each
S1104
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
8200271Associated Numbers
3804470C92 8200271 91-01-4787 M105R2511SE TS-1811 UD30042SSpecifications
| Kilowatt | 3.30 kW |
| Length (L.1) | 348 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| Mount Hole Diameter (C.3) | 10.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| INTERNATIONAL | 3000 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 3000 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 3900 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 3900 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 4000 6.0 | [VT-365] | 01.2002-12.2007 |
| INTERNATIONAL | 4900 6.0 | [VT-365] | 01.2002-12.2007 |
| INTERNATIONAL | 5000 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 5000 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 5900 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 5900 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 7100 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 7100 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 7700 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 7700 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 8100 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 8100 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 8600 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 8600 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 9100 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 9100 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | 9900 6.0 | [VT-365] | 01.2002-12.2004 |
| INTERNATIONAL | 9900 6.0 | [VT-365] | 01.2005-12.2006 |
| INTERNATIONAL | Durastar 6.4 | 01.2008-12.2014 | |
| INTERNATIONAL | TeRastar 6.4 | 01.2010-12.2013 |
Reference Information
| 3804470C92 | NAVISTAR |
| 8200271 | DELCO |
| 91-01-4787 | WILSON |
| M105R2511SE | PRESTOLITE |
| TS-1811 | DIXIE |
| UD30042S | AS-PL |
Video/Publications
