Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 611.60 including GST
NZ$ 531.83 excluding GST
or four payments of $152.90
with
Learn More
each
S1138S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
4937470 5263841 5264447 5286413 8200911 UD12911SSpecifications
| Kilowatt | 5 kW |
| Length (L.1) | 306 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 88.50 mm |
| Unit Type | DELCO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CUMMINS | Engine 3.6 | [ISF] | |
| CUMMINS | Engine 3.8 | [ISF] | |
| GAZ | 33106 | ||
| PAZ | 43253 |
Reference Information
5286413 5264447 4937470 STD5911 8200911 5263841 6060636.0 CST60636AS 20409636BN UD12911SVideo/Publications
