Associated Numbers
19168039 201-97101 255118 8000210 8191680390 91-01-4732 S-1524 STD4210 UD13949SSpecifications
Kilowatt | 1.7 kW |
Length (L.1) | 220 mm |
Mount Hole Center - Center (O.1) | 116 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 31 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Colorado 2.9 | 01.2008-12.2012 | |
CHEVROLET | Colorado 3.7 | 01.2008-12.2012 | |
CHEVROLET | Trailblazer 4.2 | 01.2008-12.2009 | |
GMC | Canyon 2.9 | 01.2008-12.2008 | |
GMC | Canyon 2.9 | 01.2009-12.2012 | |
GMC | Canyon 3.7 | 01.2009-12.2011 | |
GMC | Canyon 3.7 | 01.2012-12.2012 | |
GMC | Envoy 4.2 | 01.2008-12.2009 | |
HUMMER | H3 3.7 | 01.2008-12.2010 | |
HUMMER | H3T 3.7 | 01.2009-12.2010 | |
ISUZU | Ascender 4.2 | 01.2008-12.2008 | |
ISUZU | i-290 2.9 | 01.2008-12.2008 | |
ISUZU | i-370 3.7 | 01.2008-12.2008 | |
SAAB | 9-7X 4.2 | 01.2008-12.2009 | |
SAAB | 9-7X 5.3 | 01.2009-12.2009 |
Reference Information
20409571BN 8191680390 STRF945 19168039 255118 STD4210 S-1524 CST60175AS 6060175 201-97101 UD13949S 8000210 6934N 91-01-4732 12609480Video/Publications
19168039 201-97101 255118 6934N 8000210 8191680390 91-01-4732 S-1524 STD4210 STRF945 UD13949SAdd Your Number
