Associated Numbers
110002 111709 130.502.092 19829N 254746D 6046110 8213380 91-27-3353 CST46110 CST46110AS CST46110ES CST46110GS CST46110OS CST46110RS DRS0301N SG0175 STH8552 STH9552 STN0552 STY6552 UD12946SSpecifications
Kilowatt | 2.2 kW |
Length (L.1) | 233 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 20 mm |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DAEWOO | Various Models | ||
ISUZU | 26 2.0 D | 01.1981-01.1995 | |
ISUZU | 27 2.2 D | 01.1985-01.1988 | |
ISUZU | 41 2.0 D | 01.1981-01.1985 | |
ISUZU | 47 2.2 D | 01.1985-01.1988 | |
ISUZU | UBS52 2.2 D | 01.1984-01.1989 | |
TCM | FC 3024 |
Reference Information
110002 DRS0301N CST46110 220577 UD12946S 19829N STH9552 STY6552 SG0175 S1156S CST46110RS 254746D CST46110AS 16501013000 CST46110ES 111709 CST46110GS 130.502.092 STH8552 CST46110OS STN0552 65262017039 8213380 65262017059 6046110 91-27-3353Video/Publications
110002 111709 130.502.092 19829N 254746D 6046110 8213380 91-27-3353 CST46110 CST46110AS CST46110ES CST46110GS CST46110OS CST46110RS DRS0301N SG0175 STH8552 STH9552 STN0552 STY6552 UD12946S S1156S 220577Add Your Number
