Associated Numbers
04801269AB 4801269AB 4801269AD 6763N 6763R 8000160 8000243 91-01-4731 91-01-4731N EAA-122136 S-1519 STD2691 UD14197SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 232 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Center - Center (O.2) | 71 mm |
Mount Hole Center - Center (O.3) | 68 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
Mount Hole Diameter (C.3) | M10x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 7 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Nitro 4.0 4WD | [EGS] | 01.2006-12.2011 |
JEEP | Wrangler 3.8 | [EGT] | 01.2006-12.2011 |
Reference Information
6763N STR2037 6763R UD14197S EAA-122136 STD2691 04801269AB 20409671BN 8000160 04801269AD CST60176AS 6060176 S-1519 8000243 4801269AD 91-01-4731N STRJ573 4801269AB 91-01-4731Video/Publications
04801269AB 4801269AD 6763N 6763R 8000160 8000243 91-01-4731 91-01-4731N EAA-122136 S-1519 STD2691 STRJ573 UD14197SAdd Your Number
