Associated Numbers
201-29208 8200521 8200816 8200882 8200884 UD15028SSpecifications
Kilowatt | 4 kW |
Length (L.1) | 305 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 24.5 mm |
Rotation | CW |
Spigot Diameter (A) | 98 mm |
Unit Type | DELCO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO | VM 220 | ||
VOLVO | VM 270 | ||
VOLVO | VM 330 |
Reference Information
8200521 8200884 8200882 201-29208 8200816 UD15028SVideo/Publications
201-29208 8200521 8200816 8200882 8200884 UD15028SAdd Your Number
