Associated Numbers
115758 20493321 250.508.082 254849 36100-2G000 36100-2G200 36100-2G300 6032123 6975N 88214175 91-01-4740 9790 CST32123 CST32123AS CST32123ES CST32123GS CST32123OS CST32123RS DRS0618 DRS0618N DS1728 DS1728N J5210527 S-1513 STD2200 STD5000 STR80178 UD46894SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 215 mm |
Mount Hole Center - Center (O.1) | 94 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 30 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Sonata | [G4KC] | 01.2005-12.2010 |
HYUNDAI | Sonata 2.0 VVTi GLS | [G4KA] | 05.2005-12.2010 |
HYUNDAI | Sonata 2.0 VVTi GLS | [G4KD] | 01.2008-12.2010 |
KIA | Carens 2.0 CVVT | [G4KA] | 09.2006- |
KIA | Magentis 2.0 | [G4KA] | 11.2005- |
Reference Information
CST32123AS DS1728 3610025020 UD46894S 115758 STD5000 DRS0618 STR80178 STD2200 CST32123RS 254849 6975N CST32123 88214175 DS1728N 6032123 STR2673 J5210527 36100-2G000 36100-2G300 36100-2G200 9790 DRS0618N S-1513 91-01-4740 CST32123OS CST32123ES CST32123GS 20493321 250.508.082Video/Publications
115758 20493321 250.508.082 254849 36100-2G000 36100-2G200 36100-2G300 6032123 6975N 88214175 91-01-4740 9790 CST32123 CST32123AS CST32123ES CST32123GS CST32123OS CST32123RS DRS0618 DRS0618N DS1728 DS1728N J5210527 S-1513 STD2200 STD5000 STR80178 UD46894SAdd Your Number
