Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 253.90 including GST
NZ$ 220.78 excluding GST
or four payments of $63.48
with
Learn More
UOM:
each
Product Code:
S1183S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
10465578Associated Numbers
101258 10465578 12564108 12570823 140-10450 19136219 201-14104 601029 601240 6449N 6449R 9000879 91-01-4382 91-01-4382N S-1460 S1100R UD20513SSpecifications
| Kilowatt | 1.60 kW |
| Length (L.1) | 232 mm |
| Mount Hole Center - Center (O.1) | 83 mm |
| Mount Hole Diameter (C.1) | 10 mm |
| Mount Hole Diameter (C.2) | 10 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 60.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CADILLAC | ESCALADE 5.7 AWD | L31 | 10.1998-10.2006 |
| CADILLAC | Escalade 5.7 V8 | RL31X | 01.1999-12.2000 |
| CHEVROLET | Astro Van 4.3 V6 | L35 | 01.1997-12.1998 |
| CHEVROLET | Avalanche 2500 8.1 | 01.2002-12.2002 | |
| CHEVROLET | Avalanche 8.1 V8 | L18 | 01.2002-12.2002 |
| CHEVROLET | Blazer 4.3 V6 | L35 | 01.1996-12.1998 |
| CHEVROLET | BLAZER S10 4.3 V6 AWD | L35(262CUL6) | 01.1994-09.2005 |
| CHEVROLET | C3500 8.1 | 01.2002-12.2002 | |
| CHEVROLET | C3500 8.1 | 01.2003-12.2003 | |
| CHEVROLET | C/K/R/V Series 5.0 V8 | L30 | 01.1999-12.1999 |
| CHEVROLET | C/K/R/V Series 5.7 V8 | L31 | 01.1994-12.2000 |
| CHEVROLET | C/K/R/V Series 7.4 V8 | L29 | 01.1994-12.2000 |
| CHEVROLET | C/K/R/V Series 8.1 V8 | L18 | 01.2001-12.2002 |
| CHEVROLET | Express 1500 5.0 | 01.2002-12.2002 | |
| CHEVROLET | Express 1500 5.7 | 01.2002-12.2002 | |
| CHEVROLET | Express 2500 5.0 | 01.2002-12.2002 | |
| CHEVROLET | Express 2500 5.7 | 01.2002-12.2002 | |
| CHEVROLET | Express 3500 5.7 | 01.2002-12.2002 | |
| CHEVROLET | Express 3500 8.1 | 01.2002-12.2002 | |
| CHEVROLET | Express Van 5.0 V8 | L30 | 01.1999-12.2002 |
| CHEVROLET | Express Van 5.7 V8 | L31 | 01.1996-12.2002 |
| CHEVROLET | Express Van 7.4 V8 | L29 | 01.1996-12.2000 |
| CHEVROLET | Express Van 8.1 V8 | L18 | 01.2001-12.2002 |
| CHEVROLET | P30 5.7 | 01.2002-12.2002 | |
| CHEVROLET | Silverado 2500 5.7 | 01.2002-12.2002 | |
| CHEVROLET | Silverado 2500 HD 8.1 | 01.2002-12.2002 | |
| CHEVROLET | Silverado 3500 8.1 | 01.2002-12.2002 | |
| CHEVROLET | Sonora 5.7 | 01.2002-12.2002 | |
| CHEVROLET | Suburban 1500 5.7 | 01.2002-12.2002 | |
| CHEVROLET | Suburban 2500 8.1 | 01.2002-12.2002 | |
| GMC | Savana 1500 5.0 | 01.2002-12.2002 | |
| GMC | Savana 1500 5.7 | 01.2002-12.2002 | |
| GMC | Savana 2500 5.0 | 01.2002-12.2002 | |
| GMC | Savana 2500 5.7 | 01.2002-12.2002 | |
| GMC | Savana 3500 5.7 | 01.2002-12.2002 | |
| GMC | Savana 3500 8.1 | 01.2002-12.2002 | |
| GMC | Sierra 2500 HD 8.1 | 01.2002-12.2002 | |
| GMC | Sierra 3500 8.1 | 01.2002-12.2002 | |
| GMC | Yukon XL 2500 8.1 | 01.2002-12.2002 |
Reference Information
| 101258 | KUHNER |
| 10465578 | DELCO |
| 12564108 | DELCO |
| 12570823 | DELCO |
| 19136219 | DELCO |
| 201-14104 | DIXIE |
| 601029 | KUHNER |
| 6449N | WAI |
| 6449NM | WAI |
| 6449R | WAI |
| S1100R | PRESTOLITE |
| S1183S | AS-PL |
| S-1460 | DIXIE |
| UD20513S | AS-PL |
Video/Publications
