Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 266.62 including GST
NZ$ 231.84 excluding GST
or four payments of $66.66
with
Learn More
each
S1197S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
6782N 89017846 UD16841S 12581305 201-97101 S-1506 8890178460 STD0016 256178 6782 91-01-4668 91-01-4668NSpecifications
| Kilowatt | 1.70 kW |
| Length (L.1) | 220 mm |
| Mount Hole Center - Center (O.1) | 116 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 30 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.50 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BUICK | Rainier 4.2 | 01.2006-12.2007 | |
| CHEVROLET | Colorado 2.9 | 01.2007-12.2007 | |
| CHEVROLET | Colorado 3.7 | 01.2007-12.2007 | |
| CHEVROLET | Trailblazer 4.2 | 01.2006-12.2007 | |
| CHEVROLET | Trailbrazer EXT 4.2 | 01.2006-12.2006 | |
| GMC | Canyon 2.9 | 01.2007-12.2007 | |
| GMC | Canyon 3.7 | 01.2007-12.2007 | |
| GMC | Envoy 4.2 | 01.2006-12.2007 | |
| GMC | Envoy XL 4.2 | 01.2006-12.2006 | |
| HUMMER | H3 3.7 | 01.2007-12.2007 | |
| ISUZU | Ascender 4.2 | 01.2006-12.2007 | |
| ISUZU | i-290 2.9 | 01.2007-12.2007 | |
| ISUZU | i-370 3.7 | 01.2007-12.2007 | |
| SAAB | 9-7X 4.2 | 01.2006-12.2007 |
Reference Information
| 12581305 | DELCO |
| 201-97101 | DIXIE |
| 20409641BN | REAL |
| 256178 | KUHNER |
| 6060146.0 | SANDO |
| 6782 | ROBERT'S |
| 6782N | WAI / TRANSPO |
| 8890178460 | ISUZU |
| 89017846 | DELCO |
| 89018846 | GM |
| 91-01-4668 | WILSON |
| 91-01-4668N | WILSON |
| CST60146AS | CASCO |
| S-1506 | DIXIE |
| STD0016 | KRAUF |
| STR2128 | ELECTROLOG |
| UD16841S | AS-PL |
