- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
0986022830 101186 11928 20479511BN 20479511OE 20510236 20513048 22.1186 23300-00QAL 25-3042 3010 31236N 35258720 42015010 42016401 42455950 438081 455950 458226 6015115 7700273783 7700274178 7700274303 7700274351 8022830 8212211 8253634 860321 88212211 8EA737797-001 AES2236 CS1186 CST15115 CST15115AS CST15115ES CST15115GS CST15115OS CST15115RS D7E15 D7E20 DRS3775 EAA-121302 LRT00236 M002T13581 M2T13281 M2T13581 M2T48381 M93R3066SE RNLD7E15 S3021 STR54012Specifications
Kilowatt | 1 kW |
Length (L.1) | 169 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Center - Center (O.2) | 73 mm |
Mount Hole Center - Center (O.3) | 64 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 8 qty |
No./Teeth (Replaces) | 8. 9 qty |
Pinion at Rest (B) | -1 mm |
Rotation | CW |
Spigot Diameter (A) | 66 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DACIA | Logan 1.4 | [K7J710] | 02.2007- |
DACIA | Logan 1.6 | [K7M710] | 02.2007- |
DACIA | Logan 1.6 16V | 02.2006- | |
DACIA | Logan 1.6 i | [K7M710] | 09.2004- |
RENAULT | Clio 1.4 | [E7J780] | 09.1998-05.2005 |
RENAULT | Clio 1.4 16V | [K4J712] | 10.1999- |
RENAULT | Clio 1.4 16V | [K4J713] | 10.1999- |
RENAULT | Clio 1.6 | [K7M744] | 09.1998-05.2005 |
RENAULT | Clio 1.6 | [K7M745] | 09.1998-05.2005 |
RENAULT | Kangoo 1.4 | [E7J634] | 09.1998- |
RENAULT | Kangoo 1.4 | [E7J780] | 10.1997- |
RENAULT | Kangoo 1.4 | [K7J700] | 06.2000- |
RENAULT | Kangoo 1.4 | [K7J701] | 06.2000- |
RENAULT | Kangoo 1.4 Express | [E7J634] | 09.1998- |
RENAULT | Kangoo 1.4 Express | [E7J635] | 03.1998- |
RENAULT | Kangoo 1.4 Express | [K7J701] | 06.2000- |
RENAULT | Megane 1.4 | [E7J626] | 03.1999-09.2003 |
RENAULT | Megane 1.4 | [E7J764] | 01.1996-09.2003 |
RENAULT | Megane 1.4 ECO | [E7J624] | 02.1996-03.1999 |
RENAULT | Megane 1.4 i | [E7J626] | 03.1999-09.2003 |
RENAULT | Megane 1.4 i | [E7J764] | 01.1996-09.2003 |
RENAULT | Thalia 1.4 | 05.2001- |
Reference Information
M002T13581 M002T13582 S3021 6015115.1 RNLD7E15 331338 AES2236 D7E15 42015010 986022830 7700274178 570.544.083.008 115442 23300-00QAL ANM15995X 20513048 570.544.083.000 STR54012 LRT236 860321 25-3042 CGB-23775 STM1114 88212211 D7E20 EAA-121302 STRS001 3010 S12VA0191A2 STR5349 220389 M2T13582 8212211 CST15115GS M2T13581 20479511BN 8EA737797-001 6015115 220150 20479511OE 7700274303 570.544.083.770 STR0051 8200590412 8022830 M002T13281 42455950 8253634 8200584654 7700274351 438081 7700273783 11928 42016401 M2T48381 20510236 STA0222R 22.1186 101186 31236N CST15115AS 7711134532 M2T13281 7711134533 000986022830 5015156 LRT00236 M002T48381 CS1186 MAV171150 DRS3775 458226 455950 35258720Video/Publications
0986022830 101186 115442 11928 20479511BN 20479511OE 20510236 20513048 22.1186 220389 23300-00QAL 25-3042 3010 31236N 35258720 42015010 42016401 42455950 438081 458226 6015115 7700273783 7700274178 7700274303 7700274351 8022830 8212211 8253634 860321 88212211 8EA737797-001 AES2236 CGB-23775 CS1186 CST15115 CST15115AS CST15115ES CST15115GS CST15115OS CST15115RS D7E15 D7E20 DRS3775 EAA-121302 LRT00236 M002T13281 M002T13581 M2T13281 M2T13581 M2T48381 M93R3066SE MAV171150 RNLD7E15 S3021 STR54012 STRS001 220150Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
