Associated Numbers
10.130.172 10126 1094 11.130.007 11.130.034 11.130.134 110856 111100 11157 11346 18358N 20479141BN 20479351BN 20479351RC 22.0094 22.0126 32041N 3419 3497 42001157 432557 433243 532021 532023 5426014 5433495 5490308 5491448 6015141 6015153 6136 6185 6202 6202A 6202B 6202C 6202D 6202F 6219 75491723 75492566 7700561416 7700621302 7701348746 7701381632 7701499199 8011671 8011731 8212358 9000141015 9000141104 95494247 95580161 AZE0303 AZE0305 CS126 CS94 CST15141AS CST15153AS CST15153RS D6RA42 D6RA43 D6RA431 D8E111 D8E116 D8E130 D8E131 D8E148 D8E54 D8E70 D8E74 D8E86 D8E99 D9E92 D9E93 DRS1671 EAA-121396Specifications
Kilowatt | 0.6 kW |
Length (L.1) | 209 mm |
Mount Hole Center - Center (O.1) | 106 mm |
Mount Hole Diameter (C.1) | 8.5 mm |
Mount Hole Diameter (C.2) | 8.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | ACW |
Spigot Diameter (A) | 66 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | Fuego 1.4 | [847720] | 02.1980-10.1985 |
RENAULT | R4 0.8 | [800] | 10.1962-09.1983 |
RENAULT | R4 0.8 | [80001] | 09.1966-12.1988 |
RENAULT | R4 0.8 | [80001] | 09.1971-12.1988 |
RENAULT | R4 0.8 | [800705] | 04.1983-07.1989 |
RENAULT | R4 0.8 | [800705] | 10.1983-10.1988 |
RENAULT | R4 0.8 | [B1B707] | 04.1983-07.1989 |
RENAULT | R4 0.8 | [B1B707] | 10.1983-10.1988 |
RENAULT | R5 0.8 | [800710] | 01.1982-12.1984 |
RENAULT | Rodeo 0.8 4 | [80001] | 08.1971-11.1981 |
Reference Information
6015153.2 7701348746 11011670 MTA12P-7 432557 8EA726250-001 220114 310000 532021A 20479351BN CST15153RS 11.130.134 CS94 220114A 11346 7700621302 AZE0303 D8E111 5015858 220109 3497 ANM13891X PRSL224 110856 0009000330107 7701381632 D8E70 6015153 7701033199 D8E74 7701499647 310407 MOC12-7 SG0941 MAV171530 7700503371 433243 DS2781 9000330107 MTA12-7 6136 S3086 310030W 532023 532023A 532021 6219A S12VA0363A2 6219B 6219C D9E92 11.130.034 7700561416 STR00213 D8E86 EAA-111547 D6RA421 7701499199 D8E131 6185 CST15153AS 7701499472 D8E130 20479351RC A003T02192 D8E54 STR00098 1094 AES2103 RNL1167 7701035797 7701351393 8011671 D6RA42 DRS1671 6219 STV0094Video/Publications
1094 11.130.034 11.130.134 11011670 110856 11346 20479351BN 20479351RC 220114A 310000 310030W 310407 3497 432557 433243 532021 532021A 532023 532023A 6015153.0 6015153.2 6136 6185 6219 6219A 6219B 6219C 7700503371 7700561416 7700621302 7701033199 7701035797 7701348746 7701351393 7701381632 7701499199 7701499472 7701499647 8011671 8EA726250-001 9000330107 AES2103 AZE0303 CS94 CST15153AS CST15153RS D6RA42 D6RA421 D8E111 D8E130 D8E131 D8E54 D8E70 D8E74 D8E86 D9E92 DRS1671 DS2781 EAA-111547 MAV171530 MOC12-7 MTA12-7 MTA12P-7 PRSL224 RNL1167 S3086 SG0941 STV0094 220109Add Your Number
