Associated Numbers
D9E104A UD02160SSpecifications
| Kilowatt | 1 kW |
| Length (L.1) | 235 mm |
| Mount Hole Center - Center (O.1) | 114 mm |
| Mount Hole Center - Center (O.2) | 80 mm |
| Mount Hole Center - Center (O.3) | 80 mm |
| Mount Hole Diameter (C.1) | M7x1.0 mm |
| Mount Hole Diameter (C.2) | M7x1.0 mm |
| Mount Hole Diameter (C.3) | M7x1.0 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 46 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 99.5 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | C35 2.0 | 01.1973-12.1994 | |
| CITROEN | ID 19 2.0 Super | [B20700] | 01.1970-12.1971 |
| HONDA | City 55 1.2 | 01.1984-12.1986 | |
| HONDA | Fit 55 1.2 | 01.1984-12.1986 | |
| HONDA | Jazz 55 1.2 | 01.1984-12.1986 |
Reference Information
95493002 5455471 96036658 D9E104 D9E104A 5802P2 432562 95591700 6201 CST15259AS 6215A 95653969 UD02160S 5455469 6215B 5402233 6215C 6201A 6215D 20479952OE 6215F 6215 95591700R 6015259 STRF036 UD17054SVideo/Publications
432562 D9E104 D9E104A STRF036 UD02160S UD17054SAdd Your Number
