Associated Numbers
115977 1195912 1250313 150.565.082 16100 19023N 19023R 20493631OE 220499 25-4176 254615V 36100-3E020 36100-3E100 6032136 8080322 91-20-3557 AEY2504 CST32136 CST32136AS CST32136ES CST32136GS CST32136OS CST32136RS DRS0654 J5210523 LRS02504 PXPSA-027 S-6564 UD02618S UD02619S UD12915SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 220 mm |
Mount Hole Center - Center (O.1) | 97 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 8 qty |
Pinion at Rest (B) | 10.5 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Santa Fe 2.7 V6 | [G6BA] | 01.2006- |
HYUNDAI | Santa Fe 2.7 V6 | [G6EA] | 01.2006- |
HYUNDAI | Santa Fe 2.7 V6 4X4 | [G6BA] | 01.2006- |
HYUNDAI | Santa Fe 2.7 V6 4X4 | [G6EA] | 01.2006- |
HYUNDAI | Santa Fe 2.7 V6 GLS | [G6EA] | 03.2006-12.2009 |
HYUNDAI | Santa Fe 2.7 V6 GLS 4X4 | [G6EA] | 03.2006-12.2009 |
KIA | Carnival 2.7 V6 | [G6BA] | 01.2006- |
KIA | Grand Carnival 2.7 V6 | [G6BA] | 01.2006- |
KIA | Magentis 2.7 V6 | [G6EA] | 01.2005- |
KIA | Optima 2.7 | 01.2006-12.2010 | |
KIA | Rondo 2.7 | 01.2007-12.2012 |
Reference Information
S-6564 6032136 91-20-3557 UD02618S 115977 220499 AEY2504 220853 S12VA0557A2 CST32136OS 254615V DRS0654 CST32136GS CST32136ES 150.565.082 25-4176 36100-3E020 S3106 20493631OE CST32136 STR0116 UD12915S 36100-3E100 LRS2504 5015879 CST32136AS 16100 UD02619S J5210523 ANM12874X 8080322 19023N 1195912 PXPSA-027 CST32136RS 1250313 LRS02504 19023RVideo/Publications
115977 1195912 1250313 150.565.082 16100 19023N 19023R 20493631OE 220499 25-4176 254615V 36100-3E020 36100-3E100 6032136 8080322 91-20-3557 AEY2504 CST32136 CST32136AS CST32136ES CST32136GS CST32136OS CST32136RS DRS0654 J5210523 LRS02504 LRS2504 PXPSA-027 S-6564 UD02618S UD02619S UD12915S 220853Add Your Number
