Associated Numbers
0986011651 0986011830 0986011838 10315 1095 11.130.193 11.130.378 110866 16756R 20500463 25-0319 25-1137 432565 433246 433247 534032 534047 7700572689 7700650287 7700694096 7700750305 7700750306 7701349591 7701499468 7701499473 7701499649 8EA726066-001 AES4153 AES4163 AZF3509 AZF3545 CS315 D9E278 D9E46 D9E55 D9E63 D9E68 D9E78 D9E79 DRS1831 EAA-121239 GS432565-A LRS00453 LRS00463 ND057 RNL1183 S3014 STR54040 UD00044S VS142Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 197 mm |
Mount Hole Center - Center (O.1) | 75 mm |
Mount Hole Center - Center (O.2) | 75 mm |
Mount Hole Center - Center (O.3) | 105 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | 8.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 10.5 mm |
Rotation | CW |
Spigot Diameter (A) | 66 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | R12 1.3 | [810] | 06.1980-08.1980 |
RENAULT | R12 1.3 | [810-06] | 06.1980-08.1980 |
RENAULT | R12 1.3 Turbo TS | [810-06] | 06.1980-08.1980 |
RENAULT | R4 1.1 | [688711] | 12.1981-07.1989 |
RENAULT | R4 1.1 | [688712] | 12.1981-12.1993 |
RENAULT | R4 1.1 | [C1E714] | 12.1981-12.1993 |
RENAULT | R4 1.1 | [C1E718] | 12.1981-12.1993 |
RENAULT | R4 1.1 | [C1E719] | 07.1982-12.1993 |
RENAULT | R5 1.1 | [C1E726] | 10.1979-12.1985 |
RENAULT | R5 1.4 | [847712] | 06.1982-09.1984 |
RENAULT | R5 1.4 Alpine A5 | [840725] | 09.1977-09.1981 |
RENAULT | R5 1.4 Turbo | [840730] | 06.1980-01.1985 |
RENAULT | R5 1.4 Turbo Alpine | [840726] | 10.1981-01.1985 |
RENAULT | R5 1.4 Turbo Alpine | [C6J750] | 10.1981-01.1985 |
RENAULT | Trafic 1.4 | [847700] | 03.1980-04.1989 |
RENAULT | Trafic 1.4 | [847701] | 03.1980-04.1989 |
RENAULT | Trafic 1.4 | [C1J700] | 03.1980-10.1997 |
Reference Information
MTS12-50 DM92140 8EA726066-001 7700569256 CST15193RS LRS463 7700569257 7701351523 D9E46 534032 88212926 7701499649 ND057 25-1137 7702106485 7700509355 986011830 6021330030 000986011651 STR54040 7701499200 110367 7701348964 25-0319 5001668 5001669 DM2146 DM2140 7700543483 000986011838 AZF3509 7700622951 7702007262 20479391RC 1095 16756R D9E278 VS142 8011831 20479391BN LRS00463 STRL074 DRS1831 986011651 000986011830 LRS453 433246 433247 7700694096 7700694095 90310434 6015193.2 D9E78 D9E79 7701351394 110866 LRS00453 11.130.378 220943 ANM14051X 7700650287 6015193 7700572689 1516730R 7701381633 RNL1183 MAV171930 6000559751 7700638420 7700750305 7700714640 22.0315 7700750306 SS339 986011838 PRSL074 D9E55 534047 20500463 570.010.093.008 7702046211 7702111083 10315 EAA-121239 STR00133 AES4153 1516822R 11364 S12VA0812A2 11363 GS432565-A 7702102137 432565 7701499473 7700751266 AZF3545 D9E68 SS169 11.130.193 CST15193AS CS315 7702004621 AES4163 D9E63 SS161 7700509855 3500 7701349591 77337430 7701499468 MAV171510Video/Publications
0986011651 0986011830 0986011838 10315 1095 11.130.193 11.130.378 110367 110866 16756R 20500463 25-0319 25-1137 432565 433246 433247 534032 534047 7700572689 7700650287 7700694096 7700750305 7700750306 7701349591 7701499468 7701499473 7701499649 8EA726066-001 AES4153 AES4163 AZF3509 AZF3545 CS315 D9E278 D9E46 D9E55 D9E63 D9E68 D9E78 D9E79 DRS1831 EAA-121239 GS432565-A LRS00453 LRS00463 LRS453 LRS463 MAV171510 MAV171930 ND057 RNL1183 S3014 STR54040 STRL074 UD00044S VS142 220943Add Your Number
