Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 220.18 including GST
NZ$ 191.46 excluding GST
or four payments of $55.05
with
Learn More
each
S1108S
S3132S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
36100-2E500Associated Numbers
1195411 150.572.112 19224N 25-4346 255715V 36100-2B120 36100-2E120 36100-2E500 36100-2E550 6032144 88214541 91-20-3566 AEY2674 CST32144 CST32144AS CST32144ES CST32144GS CST32144OS CST32144RS DRS0816 DRS0816N LRS02674 S-6569 STA3626 UD13958SSpecifications
| Kilowatt | 1.20 kW |
| Length (L.1) | 198 mm |
| Mount Hole Center - Center (O.1) | 95 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 19.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Elantra 1.8 | 01.2011-12.2014 | |
| HYUNDAI | Elantra 2.0 | 01.2014-12.2014 | |
| HYUNDAI | i40 2.0 CWT | [G4NA] | 01.2012-12.2013 |
| HYUNDAI | i40 2.0 GDi | [G4NC] | 01.2011-12.2013 |
| KIA | Carens 2.0 GDi | [G4NC] | 01.2013-12.2013 |
| KIA | Optima 2.0 CVVT Hybrid | [G4NE] | 01.2012-12.2013 |
| KIA | Soul 2.0 | 01.2012-12.2013 |
Reference Information
| 1195411 | VALEO |
| 150.572.112 | PSH |
| 19224N | WAI / TRANSPO |
| 25-4346 | ELSTOCK |
| 255715V | KUHNER |
| 36100-2B120 | HYUNDAI / KIA |
| 36100-2E120 | HYUNDAI / KIA |
| 361002E120B | HYUNDAI / KIA |
| 36100-2E500 | HYUNDAI / KIA |
| 36100-2E550 | HYUNDAI / KIA |
| 600216 | VALEO |
| 6032144 | SANDO |
| 88214541 | POWERMAX |
| 91-20-3566 | WILSON |
| AEY2674 | AUTOELECTRO |
| CST32144 | CASCO |
| CST32144AS | CASCO |
| CST32144ES | CASCO |
| CST32144GS | CASCO |
| CST32144OS | CASCO |
| CST32144RS | CASCO |
| DRS0816 | DELCO |
| DRS0816N | DELCO |
| LRS02674 | LUCAS |
| LRS2674 | LUCAS |
| S130.392 | PSH |
| S144.602 | PSH |
| S3132S | AS-PL |
| S-6569 | DIXIE |
| STA3626 | KRAUF |
| STR0121 | ELECTROLOG |
| STX210224 | STARDAX |
| STX210224R | STARDAX |
| UD13958S | AS-PL |
Video/Publications
