Remanufactured AS-PL Starter motor
PREMIUM LINE
AS-PL
VALEO
Price:
NZ$ 251.68 including GST
NZ$ 218.85 excluding GST
or four payments of $62.92
with
Learn More
each
S3150PR
No stock in NZ currently
No stock in NZ currently
Associated Numbers
077911023J 077911023JX 077911023K 077911023KX 115744 12155 17888R 25-3316 254154V 300.572.093 3134 458182 6015184 77911023K 77911023KX 88214475 91-20-3545 AEY1749 CST15184 CST15184AS CST15184ES CST15184GS CST15184OS CST15184RS D7GS17 D7GS7 D7GSP7 DRS3886 DS4996 EAA-123028 LRS01749 LRS1749 S-6557 SG1139 STV4717 VAL438167Specifications
| Kilowatt | 1.70 kW |
| Length (L.1) | 209 mm |
| Mount Hole Center - Center (O.1) | 114 mm |
| Mount Hole Center - Center (O.2) | 16 mm |
| Mount Hole Center - Center (O.3) | 121 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 23 mm |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A8 3.7 Quattro | [BFL] | 10.2002-05.2006 |
| AUDI | A8 4.2 FSi Quattro | [BVJ] | 06.2006-07.2010 |
| AUDI | A8 4.2 Quattro | [BFM] | 10.2002-07.2010 |
| VW | Touareg 4.2 V8 | [AXQ] | 12.2002- |
| VW | Touareg 4.2 V8 | [BHX] | 12.2002- |
| VW | Touareg 5.0 TDi | [AYH] | 10.2002- |
| VW | Touareg 5.0 TDi | [BLE] | 10.2002- |
| VW | Touareg 5.0 TDi | [BWF] | 10.2002- |
Reference Information
| 077911023J | VW |
| 077911023JX | VW |
| 077911023K | VW |
| 077911023KX | VW |
| 115744 | CARGO |
| 12155 | EAI |
| 17888R | WAI / TRANSPO |
| 220969 | ERA |
| 25-3316 | ELSTOCK |
| 254154V | KUHNER |
| 300.572.093 | PSH |
| 3134 | CEVAM |
| 458182 | VALEO |
| 6015184 | SANDO |
| 77911023K | VW |
| 77911023KX | VW |
| 88214475 | POWERMAX |
| 91-20-3545 | WILSON |
| AEY1749 | AUTOELECTRO |
| CST15184 | CASCO |
| CST15184AS | CASCO |
| CST15184ES | CASCO |
| CST15184GS | CASCO |
| CST15184OS | CASCO |
| CST15184RS | CASCO |
| D7GS17 | VALEO |
| D7GS7 | VALEO |
| D7GSP7 | VALEO |
| DRS3886 | DELCO |
| DS4996 | DELCO |
| F032115744 | CARGO |
| LRS01749 | LUCAS |
| LRS1749 | LUCAS |
| MAV171840 | SIOM |
| S12VA0445 | SIDAT |
| S12VA0445A2 | SIDAT |
| S132.476 | PSH |
| S145.648 | PSH |
| S-6557 | DIXIE |
| SG1139 | GHIBAUDI |
| STR00109 | ELECTROLOG |
| STR00109A | ELECTROLOG |
| STRS457 | 3EFFE |
| STV4717 | KRAUF |
| STX201392 | STARDAX |
| VAL438167 | WOODAUTO |
Video/Publications
S3150PRView your shopping basket or Browse other items in Starter Motors.
