Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 420.98 including GST
NZ$ 366.07 excluding GST
or four payments of $105.25
with
Learn More
UOM:
each
Product Code:
S3158S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
ESW20E18Associated Numbers
12337 1902473 2033252 25-4452 255663 255663V 3237 33240N 438300 590.579.133 6015283 AEY2779 CST15283 CST15283AS CST15283ES CST15283GS CST15283OS CST15283RS CV2T-11000-AA CV2T-11000-AB CV2T-11000-AC DRS1009 ESW20E18 LRS02779 S3158S STR54195 STV8300 UD13971S VAL438300Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 236 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Center - Center (O.2) | 74 mm |
| Mount Hole Center - Center (O.3) | 83.50 mm |
| Mount Hole Diameter (C.1) | 9.50 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 13 qty |
| OEM Product | No |
| Pinion at Rest (B) | 14.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | B-Max 1.5 TDCi | [UGJC] | 01.2015-12.2016 |
| FORD | B-Max 1.5 TDCi | [XVJA] | 01.2015-12.2016 |
| FORD | B-Max 1.5 TDCi | [XVJC] | 01.2015-12.2016 |
| FORD | B-MAX (JK) 1.5 TDCi | UGJC | 10.2012- |
| FORD | B-MAX (JK) 1.5 TDCi | UGJG | 10.2012- |
| FORD | B-MAX (JK) 1.5 TDCi | XUJA | 10.2012- |
| FORD | B-MAX (JK) 1.5 TDCi | XUJB | 10.2012- |
| FORD | B-MAX (JK) 1.5 TDCi | XVJA | 04.2015- |
| FORD | B-MAX (JK) 1.5 TDCi | XVJC | 04.2015- |
| FORD | Fiesta 1.6 TDCi | [HHJC] | 01.2012- |
| FORD | Fiesta 1.6 TDCi | [HHJD] | 01.2012- |
| FORD | Fiesta 1.6 TDCi | [HHJE] | 01.2012- |
| FORD | Fiesta 1.6 TDCi | [HHJF] | 01.2012- |
| FORD | Fiesta 1.6 TDCi | [T3JA] | 01.2012- |
| FORD | Fiesta 1.6 TDCi | [TZJA] | 01.2012- |
| FORD | Fiesta 1.6 TDCi | [TZJB] | 01.2012- |
| FORD | Fiesta 1.6 TDCi | [UBJA] | 01.2012- |
| FORD | FIESTA VI (CB1, CCN) 1.6 TDCi | HHJC | 06.2008-12.2012 |
| FORD | FIESTA VI (CB1, CCN) 1.6 TDCi | HHJD | 06.2008-12.2012 |
| FORD | FIESTA VI (CB1, CCN) 1.6 TDCi | HHJE | 06.2008-12.2012 |
| FORD | FIESTA VI (CB1, CCN) 1.6 TDCi | HHJF | 06.2008-12.2012 |
| FORD | FIESTA VI (CB1, CCN) 1.6 TDCi | T3JA | 02.2010-12.2015 |
| FORD | FIESTA VI (CB1, CCN) 1.6 TDCi | TZJA | 02.2010-12.2015 |
| FORD | FIESTA VI (CB1, CCN) 1.6 TDCi | TZJB | 02.2010-12.2015 |
| FORD | FIESTA VI (CB1, CCN) 1.6 TDCi | UBJA | 06.2008-12.2012 |
| FORD | FIESTA VI Van 1.6 TDCi | HHJC | 01.2009-04.2017 |
| FORD | FIESTA VI Van 1.6 TDCi | HHJD | 01.2009-04.2017 |
| FORD | FIESTA VI Van 1.6 TDCi | HHJE | 01.2009-04.2017 |
| FORD | FIESTA VI Van 1.6 TDCi | T3JA | 02.2010-05.2015 |
| FORD | FIESTA VI Van 1.6 TDCi | TZJA | 02.2010-05.2015 |
| FORD | FIESTA VI Van 1.6 TDCi | TZJB | 02.2010-05.2015 |
| FORD | Tourneo Courier 1.6 TDCi | [T3CA] | 01.2014- |
| FORD | Tourneo Courier 1.6 TDCi | [T3CB] | 01.2014- |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | UGCA | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | UGCB | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XUCC | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XUCD | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XUCE | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XUCF | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XUCG | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XVCA | 05.2015-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XVCB | 05.2015-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XVCC | 05.2015-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XVCD | 05.2015-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XWCA | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.5 TDCi | XWCB | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.6 TDCi | T3CA | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.6 TDCi | T3CB | 02.2014-12.2023 |
| FORD | TOURNEO COURIER B460 MPV 1.6 TDCi | T3CC | 02.2014-12.2023 |
| FORD | Transit Courier 1.6 TDCi | [TZGA] | 01.2014- |
| FORD | Transit Courier 1.6 TDCi | [TZGB] | 01.2014- |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | UGCA | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | UGCB | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XUCC | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XUCD | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XUCE | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XUCF | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XUCG | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XVCA | 05.2015-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XVCB | 05.2015-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XVCC | 05.2015-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XVCD | 05.2015-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XWCA | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.5 TDCi | XWCB | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.6 TDCi | T3CA | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.6 TDCi | T3CB | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 Box Body/MPV 1.6 TDCi | T3CC | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | UGCA | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | UGCB | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XUCC | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XUCD | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XUCE | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XUCF | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XUCG | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XVCA | 05.2015-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XVCB | 05.2015-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XVCC | 05.2015-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XVCD | 05.2015-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XWCA | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.5 TDCi | XWCB | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.6 TDCi | T3CA | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.6 TDCi | T3CB | 02.2014-12.2023 |
| FORD | TRANSIT COURIER B460 MPV 1.6 TDCi | T3CC | 02.2014-12.2023 |
Reference Information
| 12337 | EAI |
| 1740048 | FORD |
| 1902473 | FORD |
| 2033252 | FORD |
| 2415032 | FORD |
| 25-4452 | ELSTOCK |
| 255663 | KUHNER |
| 255663V | KUHNER |
| 319095132 | DRI |
| 319095132 | DRI |
| 319095132 | DRI |
| 319095132 | DRI |
| 319095132 | DRI |
| 3237 | CEVAM |
| 33240N | WAI |
| 42003015 | HERTH+BUSS |
| 438300 | VALEO |
| 590.579.133 | WAI |
| 590.579.133.000 | WAI |
| 590.579.133.461 | WAI |
| 6015283 | SANDO |
| AEY2779 | AUTOELECTRO |
| CST15283 | CASCO |
| CST15283AS | CASCO |
| CST15283ES | CASCO |
| CST15283GS | CASCO |
| CST15283OS | CASCO |
| CST15283RS | CASCO |
| CV2T-11000-AA | FORD |
| CV2T-11000-AB | FORD |
| CV2T-11000-AC | FORD |
| DRS1009 | DELCO |
| ESW20E18 | VALEO |
| LRS02779 | LUCAS |
| LRS2779 | LUCAS |
| RMCV2T-11000-AC | FORD |
| S134.088 | WAI |
| S144.002 | WAI |
| S3158S | AS-PL |
| STM1329 | ROLLCO |
| STR00178 | ELECTROLOG |
| STR54195 | WOODAUTO |
| STRE504 | 3EFFE |
| STV8300 | KRAUF |
| STX210322 | STARDAX |
| STX210322R | STARDAX |
| UD13971S | AS-PL |
| VAL438300 | WOODAUTO |
Video/Publications
