Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
LUCAS
Price:
NZ$ 490.19 including GST
NZ$ 426.25 excluding GST
or four payments of $122.55
with
Learn More
each
S4002
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
26413Associated Numbers
10107 10107L 111691 17645N 17652N 20405801BN 20405801OE 20500969 22.0107 25-0355 26219 26219A 26219B 26271 26271B 26271H 26413 33395 35260950 6025108 6180 6233 700.002.103 8213191 8719 8719R 8EA725964-001 AES2115 CS107 CST25108AS CST25108GS DRS3333 LRS00215 LRS215 M100R2015SE STR25025 UD12407SSpecifications
| Kilowatt | 2.10 kW |
| Length (L.1) | 316 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| Mount Hole Diameter (C.3) | 10.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10. 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 30 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | LUCAS |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MASSEY FERGUSON | MF 260 3.3 | 01.1977-12.1988 | |
| MASSEY FERGUSON | MF 265 | 01.1981-12.1988 | |
| MASSEY FERGUSON | MF 275 | 01.1975-12.1988 | |
| MASSEY FERGUSON | MF 285 | 01.1975-12.1979 | |
| MASSEY FERGUSON | MF 390 T | 01.1991-12.1997 | |
| MASSEY FERGUSON | MF 565 | 01.1982-12.1988 | |
| MASSEY FERGUSON | MF 575 | 01.1976-12.1988 |
Reference Information
| 10107 | KUHNER |
| 10107L | KUHNER |
| 110442 | CARGO |
| 111691 | CARGO |
| 1680065M1 | MASSEY FERGUSON |
| 17645N | WAI / TRANSPO |
| 17652N | WAI / TRANSPO |
| 1873A013 | PERKINS |
| 1873A015 | PERKINS |
| 1895337R91 | MASSEY FERGUSON |
| 20405801BN | REAL |
| 20405801OE | REAL |
| 20500969 | PRESTOLITE |
| 22.0107 | LAUBER |
| 25-0355 | ELSTOCK |
| 26219 | LUCAS |
| 26219A | LUCAS |
| 26219B | LUCAS |
| 26271 | LUCAS |
| 26271B | LUCAS |
| 26271H | LUCAS |
| 26413 | LUCAS |
| 26413R | PERKINS |
| 2872D002 | PERKINS |
| 2873119 | PERKINS |
| 2873123 | PERKINS |
| 2873124 | PERKINS |
| 2873145 | PERKINS |
| 2873180 | PERKINS |
| 2873181 | PERKINS |
| 2873185 | PERKINS |
| 2873186 | PERKINS |
| 2873A015 | PERKINS |
| 2873A103 | PERKINS |
| 2873A15 | PERKINS |
| 31196 | PERKINS |
| 31197 | PERKINS |
| 33395 | EAI |
| 34237 | PERKINS |
| 35260950 | PRESTOLITE |
| 6025108 | SANDO |
| 6180 | DUCELLIER |
| 6233 | DUCELLIER |
| 700.002.103 | PSH |
| 700.002.103.030 | PSH |
| 700.002.103.100 | PSH |
| 700.002.103.108 | PSH |
| 700.002.103.311 | PSH |
| 7523002 | PERKINS |
| 7523821 | PERKINS |
| 8213191 | POWERMAX |
| 888346M1 | MASSEY FERGUSON |
| 8EA725964-001 | HELLA |
| AES2115 | AUTOELECTRO |
| CGB-23285 | AINDE |
| CS107 | HC PARTS |
| CS946 | HC PARTS |
| CST25108AS | CASCO |
| CST25108GS | CASCO |
| DRS3333 | DELCO |
| F032110442 | CARGO |
| F032111691 | CARGO |
| LRS00215 | LUCAS |
| LRS215 | LUCAS |
| M100R2015SE | PRESTOLITE |
| MAV321700 | SIOM |
| MAV3820 | SIOM |
| S4002 | AS-PL |
| SM1138 | HONDA |
| STM1204 | ROLLCO |
| STR25025 | WOODAUTO |
| STR4111 | ELECTROLOG |
| STRS139 | 3EFFE |
| STX200641 | STARDAX |
| STX200678 | STARDAX |
| UD12407S | AS-PL |
Video/Publications
