Associated Numbers
0001367069 0986018151 10703L 10703P 11.130.526 11.131.070 111737 1446802M91 1447732R1 17649N 18032N 18387N 20405101BN 20405101OE 20500107 20500968 22.0703M 24520 25-0201 26294 26294A 26294D 26294N 26357 26357B 26357D 26357H 26369 26369D 27502 27502B 27502E 27506 27518 27518B 27518E 27518F 27518H 27518J 27570 27570B 27570F 27585 27585A 27588 27588A 27592 27596 2873A030 2873B056 2873B071 33364 35259250 6025101 700.005.103 700.517.103 8018151 8212894 8735 8735R 8EA730219-001 AES9168 AZJ3151 AZJ3369 CS703 CST25101AS CST25101GS DRS3289 EAA-121174 GS367069-A LRS00195 LRS00968 LRS195 RNL195 S4013 STR25016Specifications
Kilowatt | 2.8 kW |
Length (L.1) | 315 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MASSEY FERGUSON | MF 3645 | 01.1989-12.1991 | |
MASSEY FERGUSON | MF 3655 | 01.1990-12.1995 | |
MASSEY FERGUSON | MF 3680 7.4 | [612DS] | 06.1988- |
MASSEY FERGUSON | MF 6170 | [6.365] | 01.1996- |
MASSEY FERGUSON | MF 6180 | [6.365] | 01.1996- |
MASSEY FERGUSON | MF 8120 | [6.365] | 01.1996- |
MASSEY FERGUSON | MF 8140 | [6.403] | 01.1996- |
MASSEY FERGUSON | MF 8150 | [6.403] | 01.1996- |
MASSEY FERGUSON | MF 8160 | [6.451] | 01.1996- |
MASSEY FERGUSON | MF 8240 | 01.1999- | |
MASSEY FERGUSON | MF 8250 | 01.1999- | |
MASSEY FERGUSON | MF 8260 | 01.1999- | |
MASSEY FERGUSON | MF 8270 | 01.1999- | |
MASSEY FERGUSON | MF 8280 | 01.1999- |
Reference Information
6025101.1 27518J 27518H 330845 6025101 26294N IS0526 26294R 1516799R 700.005.103.108 27520 11018150 SG0154 AZJ3151 U427224P 27518B 700.005.103.100 8018151 27518E 27518F 17649N 27585A RNL195 2873A028 2873022 20405101BN 25-0201 2873B071 8EA730219-001 26294D 26294A LRS195 714/40006 71429300R 0009004475035 27596A 27502 986018151 27588 27621 STR4105 27628 111737 27625 700.005.103.325 2873A030 26925316A LRS968 LRS00195 27585 26925316B 144773R1 700.005.103.320 9004475035 1446802M91 1447732MI 3581576M1 27511 27518 220006 26357D 26369D 26357B 27592 26357H 27596 RE37894 CGB-23289BO 27609 27502E 27607 27502B 3551773M91 26357 26925316 26359 27570B 27603 1873A053 27570F TS-4029 STR25016 714/29300-R STL0703 27607A S12LU0123A2 8212894 CST25101AS 20405101OE 26369 27570 8735 11.130.526 LRS00968 700.005.103.030 71440006 27588A 3581576R1 26294 91-17-8879N S4013 1447732R1 3581576M02A CS703 54244390 72735975 000986018151 10703L 2873001 CST25101GS STR7943 2873A001 10703P 2873B056 MS347 3930508R1 458383 700.005.103.010 3581576M01A 91-17-8879Video/Publications
0986018151 10703L 10703P 11.130.526 11018150 111737 1446802M91 1447732R1 144773R1 1516799R 17649N 1873A053 20405101BN 20405101OE 220006 25-0201 26294 26294A 26294D 26294N 26357 26357B 26357D 26357H 26359 26369 26369D 26925316 26925316A 26925316B 27502 27502B 27502E 27511 27518 27518B 27518E 27518F 27518H 27518J 27520 27570 27570B 27570F 27585 27585A 27588 27588A 27592 27596 27596A 27603 27607 27607A 27609 27621 27625 27628 2873A001 2873A028 2873A030 2873B056 2873B071 3551773M91 3581576M01A 3581576M02A 3581576M1 3581576R1 3930508R1 458383 6025101.0 6025101.1 700.005.103 71429300R 71440006 72735975 8018151 8212894 8EA730219-001 9004475035 91-17-8879 91-17-8879N AZJ3151 CGB-23289BO CS703 CST25101AS CST25101GS IS0526 LRS00195 LRS00968 LRS195 LRS968 MS347 RE37894 RNL195 S4013 SG0154 STL0703 STR25016 TS-4029 U427224PAdd Your Number
