Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 230.23 including GST
NZ$ 200.20 excluding GST
or four payments of $57.56
with
Learn More
each
S4015
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
63102003Associated Numbers
063102003010 0986017781 10981 10981M 111420 11810 20404801BN 20404801OE 20404801RC 20510146 220179 25-2081 31160N 31160R 3825 42017781 458230 46419332 500.518.093 6030108 63102003 71721250 88212708 8EA012528-331 8EA737151-001 943102003010 944280177810 AES1246 CS981 CST30108 CST30108AS CST30108ES CST30108GS CST30108OS CST30108RS DRS3308 DS4418 EAA-121314 LRT00146 MRS17781 MSN603 MSR603 SG0130 STE0981 STR52005Specifications
| Kilowatt | 0.90 kW |
| Length (L.1) | 205 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Center - Center (O.2) | 63 mm |
| Mount Hole Center - Center (O.3) | 76 mm |
| Mount Hole Diameter (C.1) | 9.50 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | 8.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 12 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Brava 1.4 | [182A5.000] | 10.1995-10.2001 |
| FIAT | Brava 1.4 12V | [182A3.000] | 10.1995-08.1998 |
| FIAT | Bravo 1.4 | [182A3.000] | 10.1995-10.2001 |
| FIAT | Bravo 1.4 | [182A5.000] | 10.1995-10.2001 |
| FIAT | Marea 1.4 80 12V | [182A3.000] | 09.1996-05.2002 |
Reference Information
| 063102003010 | MAGNETI MARELLI |
| 0986017781 | BOSCH |
| 10981 | KUHNER |
| 10981M | KUHNER |
| 111420 | CARGO |
| 11810 | EAI |
| 20404801BN | REAL |
| 20404801OE | REAL |
| 20404801RC | REAL |
| 20510146 | PRESTOLITE |
| 220179 | ERA |
| 25-2081 | ELSTOCK |
| 31160N | WAI / TRANSPO |
| 31160R | WAI / TRANSPO |
| 331133 | LOGISTIK |
| 3825 | CEVAM |
| 42017781 | HERTH+BUSS |
| 458230 | VALEO |
| 46231541 | FIAT |
| 46419332 | FIAT |
| 46419392 | FIAT |
| 500.518.093 | PSH |
| 6030108 | SANDO |
| 63102003 | MAGNETI MARELLI |
| 71721250 | FIAT |
| 88212708 | POWERMAX |
| 8EA012528-331 | HELLA |
| 8EA737151-001 | HELLA |
| 943102003010 | MAGNETI MARELLI |
| 944280177810 | MAGNETI MARELLI |
| AES1246 | AUTOELECTRO |
| ANM15528X | ANDEL |
| CS981 | HC PARTS |
| CST30108 | CASCO |
| CST30108AS | CASCO |
| CST30108ES | CASCO |
| CST30108GS | CASCO |
| CST30108OS | CASCO |
| CST30108RS | CASCO |
| DRS3308 | DELCO |
| DS4418 | DELCO |
| F032111420 | CARGO |
| LRT00146 | LUCAS |
| MAV2000 | SIOM |
| MRS17781 | MAGNETI MARELLI |
| MSN603 | MAGNETI MARELLI |
| MSR603 | MAGNETI MARELLI |
| S4015 | AS-PL |
| SG0130 | GHIBAUDI |
| STA0215R | BOVEZ |
| STE0981 | KRAUF |
| STR52005 | WOODAUTO |
| STR90007 | ELECTROLOG |
| STRS022 | 3EFFE |
| STX200216 | STARDAX |
| STX200216R | STARDAX |
Video/Publications
