S4033PR - Remanufactured AS-PL Starter motor

Name: Remanufactured AS-PL Starter motor
Brand: AS-PL
SKU: S4033PR
Price: 218.12 NZD
Availability: BackOrder

Remanufactured AS-PL Starter motor

PREMIUM LINE

Manufacturer:

AS-PL

Replacement For:

MAGNETI MARELLI

Price:

NZ$ 218.12 including GST

NZ$ 189.67 excluding GST

or four payments of $54.53 with
Learn More

UOM:

each

Product Code:

S4033PR

Quantity In Stock Nationally:

No stock in NZ - Call us for possible procurement options

Availability:

This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**

Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications

0986017041 101038 10344 1090 111585 20376 20513153 220162 25-2257 30191R 3445 42001222 432503 432564 432601 433276 438089 455958 46231500 46406970 46432301 500.515.093 6030113 63222806 63222836 63222837 63222897 63222905 63222908 7668988 7737262 88212700 943222836 944280170410 AES2134 CS1038 CST30113 CST30113AS CST30113ES CST30113GS CST30113OS CST30113RS D7E70 DRS7041 DRS7041N DS8151 DS8151N DSN585 LRS00234 MRS17041 R80C SG0217 STE1038 STR52001

Kilowatt	0.80 kW
Length (L.1)	218 mm
Mount Hole Center - Center (O.1)	89 mm
Mount Hole Center - Center (O.2)	53 mm
Mount Hole Center - Center (O.3)	67 mm
Mount Hole Diameter (C.1)	M8x1.25 mm
Mount Hole Diameter (C.2)	M8x1.25 mm
Mount Hole Diameter (C.3)	M8x1.25 mm
No./Mount holes	3 qty
No./Mount holes with thread	3 qty
No./Teeth	9 qty
OEM Product	No
Pinion at Rest (B)	13 mm
Product Line	Premium Line
Product Type	Remanufactured
Rotation	CW
Spigot Diameter (A)	62 mm
Unit Type	MAGNETI MARELLI
Voltage	12 V

Make	Model	Type	Year
AUTOBIANCHI	A 112 0.9	[A112A5.000]	01.1976-12.1978
AUTOBIANCHI	A 112 0.9	[A112A5.000]	10.1969-12.1972
AUTOBIANCHI	A 112 0.9 E	[A112A5.000]	01.1973-12.1977
AUTOBIANCHI	A 112 0.9 Junior	[A112A5.000]	07.1975-12.1985
AUTOBIANCHI	A 112 0.9 Junior	[A112B2.000]	07.1975-12.1985
AUTOBIANCHI	A 112 1.0 Abarth	[A112A1.000]	09.1971-12.1975
AUTOBIANCHI	A 112 1.0 Abarth	[A112A2.000]	01.1974-12.1984
AUTOBIANCHI	A 112 1.0 E	[A112B1.000]	11.1977-12.1985
AUTOBIANCHI	A 112 1.0 Elite	[A112B1.000]	11.1977-12.1985
AUTOBIANCHI	A 112 1.0 LX	[A112B1.000]	11.1977-12.1985
FIAT	127 0.9	[100GL.000]	09.1971-12.1984
FIAT	127 0.9	[100GL.048]	06.1971-05.1983
FIAT	127P 0.9	[100GL.000]	10.1969-10.1976
FIAT	600 0.9	[1170A1.046]	01.1998-01.2010
FIAT	600 0.9	[1170A1.046]	01.1998-01.2010
FIAT	600 0.9	[1170A1.046]	11.1997-12.2008
FIAT	Cinquecento 0.9	[170A1.000]	07.1991-12.1993
FIAT	Cinquecento 0.9 i.e.	[170A1.046]	07.1991-09.1994
FIAT	Cinquecento 0.9 i.e. S	[1170A1.000]	07.1991-07.1999
FIAT	Cinquecento 0.9 i.e. S	[1170A1.046]	07.1991-07.1999
FIAT	Fiorino 900	[100GL.000]	10.1977-10.1986
FIAT	Panda 1000	[156A3.000]	01.1985-12.1992
FIAT	Panda 750	[141B.000]	01.1986-07.1992
FIAT	Panda 750	[156A4.000]	01.1986-10.2003
FIAT	Panda 750		01.1986-01.1995
FIAT	Panda 750 Cat		01.1995-10.2003
FIAT	Panda 800	[100GL6.000]	02.1981-12.1985
FIAT	Panda 900	[100GL3.000]	10.1980-06.1994
FIAT	Panda 900	[1170A1.046]	04.1992-12.1996
FIAT	Panda 900	[146A.000]	10.1980-06.1994
FIAT	Panda 950 4x4	[A112B1.054]	09.1983-12.1986
FIAT	Seicento 0.9	[1170A1.046]	01.1998-01.2010
FIAT	Seicento 0.9	[1170A1.046]	11.1997-12.2008
FIAT	Uno 45 0.9	[146A.000]	03.1983-09.1992
FIAT	Uno 45 0.9	[146A1.000]	03.1983-09.1992
FIAT	Uno 45 i.e. 1.0	[156A2.246]	04.1984-10.1995
INNOCENTI	Koral 45	[100GL.064]	01.1990-12.1992
LANCIA	A 112 0.9 Junior	[A112A.000]	03.1981-06.1986
LANCIA	A 112 0.9 Junior	[A112A5.000]	03.1981-06.1986
LANCIA	A 112 0.9 Junior	[A112B2.000]	03.1981-06.1986
LANCIA	A 112 1.0 LX	[A112B1.000]	03.1984-12.1986
SEAT	127 0.9	[A112A5.000]	04.1972-12.1982
SEAT	Fura 0.9	[09NCA]	03.1984-12.1986
SEAT	Fura 0.9	[100GL3000]	01.1982-06.1986
SEAT	Fura 0.9	[100GL7000]	03.1984-12.1986
SEAT	Fura 0.9	[HB90]	01.1982-06.1986
SEAT	Ibiza 0.9	[09NCA]	08.1990-05.1993
SEAT	Ibiza 0.9	[146A000]	08.1986-05.1993
SEAT	Ibiza 0.9	[146A000]	08.1990-05.1993
SEAT	Ibiza 1.2	[021A1000]	11.1984-12.1993
SEAT	Ibiza 1.2 i	[021C.1000]	01.1989-05.1993
SEAT	Ibiza 1.5	[021A2000]	11.1984-05.1993
SEAT	Ibiza 1.5 i	[021B.2000]	10.1986-05.1993
SEAT	Ibiza 1.5 i Cat	[021C.2000]	10.1986-05.1993
SEAT	Malaga 1.2	[021A1000]	05.1985-12.1993
SEAT	Malaga 1.5	[021A2000]	05.1985-12.1993
SEAT	Malaga 1.5 i	[021B.2000]	01.1987-12.1993
SEAT	Malaga 1.5 i Cat	[021A2000]	10.1986-12.1993
SEAT	Malaga 1.5 i Cat	[021C.2000]	10.1986-12.1993
SEAT	Malaga 1.5 i Cat	[021D.2000]	10.1986-12.1993
SEAT	Marbella 0.8	[08NCA]	01.1987-12.1993
SEAT	Marbella 0.8	[08NCA]	08.1986-12.1993
SEAT	Marbella 0.9	[09NCA]	01.1987-12.1993
SEAT	Marbella 0.9	[100GL7000]	01.1987-12.1993
SEAT	Marbella 0.9 Cat	[08NCB]	11.1996-10.1998
SEAT	Marbella 0.9 Cat	[09NCB]	01.1987-12.1993
SEAT	Marbella 0.9 Cat	[09NCB]	01.1990-11.1996
SEAT	Marbella 0.9 Cat	[100GL7000]	01.1990-11.1996
SEAT	Panda 0.9	[100GL3000]	10.1980-12.1986
SEAT	Ronda 1.2	[021A1000]	10.1984-12.1986
SEAT	Ronda 1.2	[124B6.000]	08.1983-05.1985
SEAT	Ronda 1.5	[021A2000]	09.1984-12.1986
SEAT	Ronda 1.6	[022A000]	08.1983-09.1985
SEAT	Ronda 1.6	[138AR6.000]	08.1983-09.1985
SEAT	Ronda 1.7 D	[022A.5000]	06.1982-12.1986
SEAT	Terra 0.9	[09NCA]	01.1987-12.1995
SEAT	Terra 0.9 Cat	[09NCB]	02.1992-12.1994

0003914191	VW
0003974104	VW
101038	KUHNER
1090	KUHNER
110365	CARGO
111585	CARGO
20404311BN	REAL
20404311EL	REAL
20404311OE	REAL
20404311RC	REAL
20404311RE	REAL
220162A	ERA
220162R	ERA
25-2257	ELSTOCK
30191R	WAI / TRANSPO
335650	RHIAG
3914191	FIAT
3915113	FIAT
42001222	HERTH+BUSS
4229113	FIAT
4229114	FIAT
4401806	FIAT
4468806	FIAT
46231500	FIAT
46231504	FIAT
46231505	FIAT
46406970	FIAT
46432301	FIAT
46465273	FIAT
46797350	FIAT
500.013.093.050	PSH
500.013.093.058	PSH
500.013.093.265	PSH
500.515.093.265	PSH
5030230	MEAT & DORIA
5972684	FIAT
6030113.0	SANDO
6030113.1	SANDO
6030113.2	SANDO
6030113.3	SANDO
6030113.4	SANDO
63222836	MAGNETI MARELLI
63222837	MAGNETI MARELLI
63222897	MAGNETI MARELLI
63222905	MAGNETI MARELLI
63222908	MAGNETI MARELLI
71721244	FIAT
71721245	FIAT
71782312	FIAT
71782313	FIAT
71782314	FIAT
7668988	FIAT
77175430	FIAT
77201430	FIAT
7737262	FIAT
88212700	POWERMAX
8EA012526-811	HELLA
8EA737273-001	HELLA
943222836	MAGNETI MARELLI
CGB-52257	AINDE
CS1038	HC PARTS
CS90	HC PARTS
CST30113AS	CASCO
CST30113ES	CASCO
CST30113GS	CASCO
CST30113OS	CASCO
CST30113RS	CASCO
DENDSN585	WOODAUTO
DRS7041	DELCO
DRS7041N	DELCO
DRS7041X	DELCO
DSN585	DENSO
F032110365	CARGO
F032111585	CARGO
GS222905-A	GPARTS
GS222905M-R	GPARTS
HB90800002	VW
HB90800004	VW
IS0586	ISKRA / LETRIKA
LRS00234	LUCAS
LRS234	LUCAS
MAHMS382	WOODAUTO
MAV1030A	SIOM
PRSL138	3EFFE
S12MA0055A2	SIDAT
SE21908000	VW
SE21908000A	VW
SG0141	GHIBAUDI
SS222905-A	GPARTS
SS222905M-R	GPARTS
STE1038	KRAUF
STR00295	ELECTROLOG
STR52001	WOODAUTO
STR52020	WOODAUTO
STR9076	ELECTROLOG
STRL138	3EFFE
STX200183	STARDAX
STX200183R	STARDAX
STX200329	STARDAX
STX200501	STARDAX
XO39466650	VW
XO39741040	VW

S4033PR
