Brand new OEM MAGNETI MARELLI Starter motor
PREMIUM LINE
Magneti Marelli
MAGNETI MARELLI
Price:
NZ$ 813.23 including GST
NZ$ 707.16 excluding GST
or four payments of $203.31
with
Learn More
each
S4070(MM)
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
112390 UD18360S 26-3314 11.131.100 AZE1227 IS1010 25219 25219K 26631 26631A 26631E 27018 27018A 27018B LRS00270 63226631 63226631010 72736061 MS433 66925191 680.504.093 182-30335 UNIT BOM 180-129 UNIT BOM 182-447 91-17-8841 STR25006Specifications
| Kilowatt | 0.90 kW |
| Length (L.1) | 204 mm |
| Mount Hole Center - Center (O.1) | 80 mm |
| Mount Hole Center - Center (O.2) | 80 mm |
| Mount Hole Center - Center (O.3) | 114 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | Yes |
| Pinion at Rest (B) | 27 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | ACW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LISTER | Engine | ||
| LISTER PETTER | Engine |
Reference Information
| 11.131.100 | ISKRA / LETRIKA |
| 112390 | CARGO |
| 182-30335 | ROBERT'S |
| 20419712OE | REAL |
| 25219 | LUCAS |
| 25219K | LUCAS |
| 26-3314 | ELSTOCK |
| 26631 | LUCAS |
| 26631A | LUCAS |
| 26631E | LUCAS |
| 27018 | LUCAS |
| 27018A | LUCAS |
| 27018B | LUCAS |
| 332012 | LOGISTIK |
| 375850 | LISTER PETTER |
| 6021217.1 | SANDO |
| 63226631 | MAGNETI MARELLI |
| 63226631010 | MAGNETI MARELLI |
| 66925191 | PRESTOLITE |
| 680.504.093 | PSH |
| 72736061 | MAHLE |
| 91-17-8841 | WILSON |
| AZE1227 | ISKRA / LETRIKA |
| CST21217GS | CASCO |
| IS1010 | ISKRA / LETRIKA |
| LRS00270 | LUCAS |
| LRS270 | LUCAS |
| MAV232170 | SIOM |
| MS433 | MAHLE |
| MS 433 | MAHLE |
| STR25006 | WOODAUTO |
| STR79133 | ELECTROLOG |
| UD18360S | AS-PL |
| UNIT BOM 180-129 | WAI / TRANSPO |
| UNIT BOM 182-447 | WAI / TRANSPO |
