Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 416.43 including GST
NZ$ 362.11 excluding GST
or four payments of $104.11
with
Learn More
each
S5101
1
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
M2T84471Associated Numbers
114613 17710 17710N 25-3319 254866 31200-P5A-A01 31200-Y3004 31200-Y3014 31200-Y3024 DRS0419 M001T84081 M002T80081 M002T80681 M002T84081 M002T84471 M1T84081 M2T80081 M2T80681 M2T84081 M2T84471 MHG006 MHG007 STR71070 31200P5A005 m1T84082 m001t84082
16452
Specifications
| Kilowatt | 1.60 kW |
| Length (L.1) | 252 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 51 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Legend 3.2 i V6 | [C32A] | 01.1991-12.1996 |
| HONDA | Legend 3.5 V6 | [C35A2] | 01.1996-12.2006 |
| HONDA | Legend 3.5 V6 4WD | [J35A8] | 01.2004-12.2008 |
Reference Information
| 114613 | CARGO |
| 17710 | WAI / TRANSPO |
| 17710N | WAI / TRANSPO |
| 25-3319 | ELSTOCK |
| 254866 | KUHNER |
| 31200-P5A-A01 | HONDA |
| 31200-P5A-A02 | HONDA |
| 31200-PAA05 | HONDA |
| 31200-PY3-024 | HONDA |
| 31200-PY3-A01 | HONDA |
| 31200-Y3004 | HONDA |
| 31200-Y3014 | HONDA |
| 31200-Y3024 | HONDA |
| 31200-Y3A01 | HONDA |
| ANM12639X | ANDEL |
| DRS0419 | DELCO |
| F032114613 | CARGO |
| M001T84081 | MITSUBISHI |
| M002T80081 | MITSUBISHI |
| M002T80681 | MITSUBISHI |
| M002T84081 | MITSUBISHI |
| M002T84471 | MITSUBISHI |
| M002T84472 | MITSUBISHI |
| M1T84081 | MITSUBISHI |
| M2T80081 | MITSUBISHI |
| M2T80681 | MITSUBISHI |
| M2T84081 | MITSUBISHI |
| M2T84471 | MITSUBISHI |
| M2T84472 | MITSUBISHI |
| MHG006 | HONDA |
| MHG007 | HONDA |
| STR5293 | ELECTROLOG |
| STR71070 | WOODAUTO |
| STRF257 | 3EFFE |
