Associated Numbers
66925301 91-27-3115 M001T74781 M001T74781A M001T74785 M1T74781 M1T74781A M1T74785 S1182M STR71139Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 255 mm |
Mount Hole Center - Center (O.1) | 116 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 8 qty |
No./Teeth (Replaces) | 8 qty |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
INFINITI | Q45 4.5 |
Reference Information
M1T74781 STRF569 M1T74785 M001T74781A 23300-60U15 M001T74785 S1182M 23300-60U11 23300-60U12 M001T74781 17180N 23300-60U10 STR71139 66925301 M1T74781A STM2580 STR5135 91-27-3115Video/Publications
23300-60U10 23300-60U11 23300-60U12 23300-60U15 66925301 91-27-3115 M001T74781 M001T74781A M001T74785 M1T74781 M1T74781A M1T74785 S1182M STM2580 STR71139 STRF569Add Your Number
