S5124 - Brand new AS-PL Starter motor

Brand new AS-PL Starter motor
Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 286.62 including GST

NZ$ 249.23 excluding GST
each
S5124
No stock in NZ
Item available to backorder, submit your order. Aprox 7-14 day delay - $40 Air freight charge additional
Purchase Qty:

112846 17559N 20437422BN 22.3162 25-2443 255068 4609058 6035224 CST35224 CST35224AS CST35224ES CST35224GS CST35224OS CST35224RS DRZ5184 EAA-121662 LRS01495 M001T78581 M001T78581ZC M1T78581 M1T78581ZC
Kilowatt1.4 kW
Length (L.1)231 mm
Mount Hole Center - Center (O.1)113 mm
Mount Hole Center - Center (O.2)71 mm
Mount Hole Center - Center (O.3)68 mm
Mount Hole Diameter (C.1)M10x1.5 mm
Mount Hole Diameter (C.2)M10x1.5 mm
Mount Hole Diameter (C.3)M10x1.5 mm
No./Mount holes3 qty
No./Mount holes with thread3 qty
No./Teeth10 qty
No./Teeth (Replaces)10 qty
Pinion at Rest (B)8 mm
RotationCW
Spigot Diameter (A)82 mm
Unit TypeMITSUBISHI
Voltage12 V
Make Model Type Year
CHRYSLER CiRus 2.5 [EEB] 01.1998-01.1998
CHRYSLER CiRus 2.5 01.1999-01.2000
CHRYSLER CiRus 2.5 LX [EEB] 01.1995-01.1997
CHRYSLER CiRus 2.5 LX [EEB] 10.1994-09.2000
CHRYSLER CiRus 2.5 LXI [EEB] 01.1995-01.1997
CHRYSLER Sebring 2.5 JX [EEB] 01.1996-01.1997
CHRYSLER Sebring 2.5 JX [EEB] 01.1998-01.1998
CHRYSLER Sebring 2.5 JX 01.1999-01.2000
CHRYSLER Sebring 2.5 JXI [EEB] 01.1996-01.1997
CHRYSLER Sebring 2.5 JXI [EEB] 01.1998-01.1998
CHRYSLER Sebring 2.5 JXI 01.1999-01.2000
CHRYSLER Sebring 2.5 LE [EEB] 05.1995-09.2000
CHRYSLER Sebring 2.5 LX [EEB] 01.1996-
CHRYSLER Sebring 2.5 LX 01.1999-01.1999
CHRYSLER Sebring 2.5 LXI [EEB] 01.1996-01.1997
CHRYSLER Sebring 2.5 LXI [EEB] 01.1998-01.1998
CHRYSLER Sebring 2.5 LXI 01.1999-01.1999
DODGE Stratus 2.5 01.1999-01.2000
DODGE Stratus 2.5 ES [EEB] 01.1995-01.1997
DODGE Stratus 2.5 ES [EEB] 01.1998-01.1998
DODGE Stratus 2.5 V6 [EEB] 12.1995-04.2001
4609058 17559N DRZ5184 M0T80481 112846 4671101 CST35224AS M1T78581ZC M1T78581 M001T78581ZC CST35224RS R4609058 CST35224OS ANM97404X 22.3162 LRS1495 CGB-28581 CST35224GS CST35224ES 336237 EAA-121662 20437422BN M001T78581 25-2443 LRS01495 255068 STR5144 M000T80481 6035224 STRF671 CST35224
112846 17559N 20437422BN 22.3162 25-2443 255068 4609058 6035224 CGB-28581 CST35224 CST35224AS CST35224ES CST35224GS CST35224OS CST35224RS DRZ5184 EAA-121662 LRS01495 LRS1495 M001T78581 M001T78581ZC M1T78581 M1T78581ZC STRF671
