Associated Numbers
0986025760 20437242OE 25-4254 254676 31100-51K00 31100-73K00 3147 4709919 6035242 8080358 8214184 88214184 93134147 AEY2561 CS1528 CST35242 CST35242AS CST35242ES CST35242GS CST35242OS CST35242RS DRS0642 LRS02582 M000T36971 M000T36971ZE M0T36971 M0T36971ZE UD30040SSpecifications
Kilowatt | 1.1 kW |
Length (L.1) | 183 mm |
Mount Hole Center - Center (O.1) | 102 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | M10x1.75 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 8 qty |
No./Teeth (Replaces) | 8 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Agila B 1.0 | [K10B] | 04.2008- |
OPEL | Agila B 1.0 LPG | [K10B] | 01.2010- |
OPEL | Agila B 1.2 | [K12B] | 04.2008- |
SUZUKI | Splash 1.0 | [K10B] | 04.2008- |
SUZUKI | Splash 1.2 | [K12B] | 04.2008- |
VAUXHALL | Agila B 1.0 | [K10B] | 04.2008- |
VAUXHALL | Agila B 1.2 | [K12B] | 04.2008- |
Reference Information
3110086G20 PRSL171 4709919 M0TD0671ZE 1202497 31100-51K00 STR5295 114871 CST35242RS S12MH0541A2 25-4254 31100M68K10 S12MH0541 000986025760 CS1528 M000T36971ZE CST35242ES CST35242AS 31100-73K00 M000T36971 M002T46981ZE STRL171 DRS0642 LRS02582 M000T33071ZM S5184 AEY2561 88214184 31100M68K10000 986025760 8214184 31243N 95520330 M000TD0671ZE 3110051K21 31100-51K21 336177 8080358 20437242OE M0T36971 93194147 CST35242GS M0T36971ZE 5035224 254676 ANM12862X M2T46981ZE 6035242 3147 CST35242 93134147 LRS2582 95514185 CST35242OS UD30040SVideo/Publications
0986025760 114871 20437242OE 25-4254 254676 31100-51K00 31100-73K00 3147 4709919 6035242 8080358 8214184 88214184 93134147 AEY2561 CS1528 CST35242 CST35242AS CST35242ES CST35242GS CST35242OS CST35242RS DRS0642 LRS02582 LRS2582 M000T36971 M000T36971ZE M0T36971 M0T36971ZE S5184 STRL171 UD30040S STR5295Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
