Associated Numbers
20437612OE 254158 6035216 CST35216GS M008T77072 M8T77072Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 271 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CASE | CX75SR 3.0 | [4JG1] | 01.2002-12.2009 |
CASE | CX80 2.2 | [4LE2X] | 01.2004-12.2009 |
GEHL | CTL70 3.0 | [4JG1] | 01.2004-12.2010 |
INGERSOLL RAND | Engine 3.0 | [4JG1] | 01.1996-12.2006 |
ISUZU | Engine 2.8 | [4JB1] | 01.1996-12.2006 |
JCB | 8052 3.0 | [4JG1] | 01.2003-12.2008 |
JCB | 8055 RTS 2.2 | [4LE1] | 01.2008-12.2012 |
JCB | 8055 RTS 2.2 | [4LE2] | 01.2008-12.2012 |
JCB | 8055 ZTS 2.2 | [4LE1] | 01.2008-12.2012 |
JCB | 8055 ZTS 2.2 | [4LE2] | 01.2008-12.2012 |
JCB | 8056 3.0 | [4JG1] | 01.2006-12.2011 |
JCB | 8060 3.0 | [4JG1] | 01.2001-12.2008 |
JCB | 8061 CTS 3.0 | [4JG1] | 01.2012-12.2014 |
JCB | 8065 DL 2.2 | [4LE1] | 01.2012-12.2014 |
JCB | 8065 RTS 2.2 | [4LE1] | 01.2008-12.2014 |
JCB | 8065 RTS 2.2 | [4LE2X] | 01.2008-12.2014 |
JCB | 8065 ZTS 2.2 | [4LE1] | 01.2008-12.2014 |
JCB | 8065 ZTS 2.2 | [4LE2X] | 01.2008-12.2014 |
JCB | 8080 3.0 | [4JG1] | 01.2003-12.2009 |
JCB | 8085 ZTS 2.2 | [4LE2X] | 01.2009-12.2014 |
MAN | F 90 35.272 VF | [D2865LF02] | 02.1990-12.1991 |
MAN | F 90 35.272 VFK | [D2865LF02] | 02.1990-12.1992 |
MUSTANG | MTL20 3.0 | [4JG1] | 01.2004-12.2008 |
TAKEUCHI | TL140 3.0 | [4JG1] | 01.2003-12.2008 |
Reference Information
LRS3988 150.548.112.371 88214482 150.548.112.130 150.548.112.370 11.139.370 STR28017 M8T76371 CST35216GS M008T77071 M008T77073 M008T97204 M008T77072 IS9576 M008T77075 M008T77074 M8T77071E S12MH0313A2 8973494020 20437612OE M8T897204 M8T77075 M8T77074 M8T77073 M8T77072 M008T77071E M8T77071 714/88901 18975N M008T897204 STM3587 M008T76371 M008T8972047 CGB-97071 S5186 8972047130 336297 130-80161N AZE4808 254158M 91-27-3345 M008T72047 6035216 LRS03988 MAV372160 M8T72047 130-80161 M8T97204 8205 MS1157 8971704000 714-40357 114038 6035216.1 72556901 254158 25-5150 M8T8972047Video/Publications
20437612OE 254158 6035216 CST35216GS M008T77072 M8T77072Add Your Number
