Associated Numbers
114169 254090 32B66-00200 32B66-20100 45-3370 EAA-121561 LRS02199 M008T60371 M008T60372 M008T60373 M8T60371 M8T60372 M8T60373 STR28018Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 287 mm |
Mount Hole Center - Center (O.1) | 55 mm |
Mount Hole Center - Center (O.2) | 95 mm |
Mount Hole Center - Center (O.3) | 56 mm |
Mount Hole Center - Center (O.4) | 97 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
Mount Hole Diameter (C.4) | 11.5 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 22 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | DP40 Mitsubishi | [S6E] | |
CATERPILLAR | PD40 | 01.1984- | |
MITSUBISHI | DP40 Mitsubishi | [S6S] | |
MITSUBISHI | FD35D2 Mitsubishi | [S6E] | |
MITSUBISHI | FD35D Mitsubishi | [S6E] | |
MITSUBISHI | FD35DS Mitsubishi | [S6E] | |
MITSUBISHI | FD38 Mitsubishi | [S6E] | |
MITSUBISHI | FD40D Mitsubishi | [S6E] | |
MITSUBISHI | FD45D Mitsubishi | [S6E] | |
MITSUBISHI | FD50C Mitsubishi | [S6E] | |
MITSUBISHI | FD50D Mitsubishi | [S6E] |
Reference Information
STRL617 254090 8214 32B6620102 32B66-00200 M008T60384AM 18246N 32B66-00202 32B66-00204 32B6620104 M8T60384 LRS02199 DS1187 M003T58771 151.513.102.130 151.513.102.370 M8T60375AM CST35613AS 32B6600402 32B6602302 M8T60375 M8T60373 336222 M8T60374 M8T60371 M8T60372 PRSL617 STR28018 CGB-20077 MAV376130 45-3370 114169 M008T60384 M8T60384AM 32B66-20100 STR5430 DRS0077 S5189 151.513.102.510 6035613 LRS2199 32B6610200 88213960 M008T60375 M008T60374 M008T60373 254090M M008T60372 EAA-121561 M008T60371 32B6600101 S24MH0132A2 M3T58771 254090BVideo/Publications
114169 254090 32B66-00200 32B66-20100 45-3370 CGB-20077 EAA-121561 LRS02199 LRS2199 M008T60371 M008T60372 M008T60373 M8T60371 M8T60372 M8T60373 MAV376130 S5189 STR28018 STRL617Add Your Number
