Associated Numbers
114185 254344 254344M 271.502.112 45-3323 6035627 8971374780 8971374781 CST35627 CST35627AS CST35627ES CST35627GS CST35627OS CST35627RS DRS0393 LRS01962 M008T80371 M008T80373 M8T80371 M8T80373 STM3884 UD14600(MITSUBISHI)SSpecifications
Kilowatt | 3.2 kW |
Length (L.1) | 258 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 20 mm |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | Engine | [4JB1] | |
KOBELCO | SK60 | [4JB1PA] | 01.1998-12.2003 |
KOBELCO | SK70 | [4JB1PA] | 01.1998-12.2003 |
Reference Information
M008T80371 CST35627ES M008T80372 M008T80373 CST35627GS M008T80374 CST35627AS LRS01962 271.502.112 714/34500 M8T80373 30027N M8T80374 254344M M8T80371 254344 M8T80372 8971374782 M8T80373AM 8971374780 CST35627RS 8971374781 LRS1962 DRS0393 M008T80373AM CST35627 M008T81571 45-3323 S24MH0134A2 114185 CST35627OS S24MH0134 STR5220 71434500R UD14600(MITSUBISHI)S M8T81571 STM3884 5135152 6035627Video/Publications
114185 254344 254344M 271.502.112 45-3323 6035627 8971374780 8971374781 CST35627 CST35627AS CST35627ES CST35627GS CST35627OS CST35627RS DRS0393 LRS01962 LRS1962 M008T80371 M008T80373 M8T80371 M8T80373 STM3884 UD14600(MITSUBISHI)SAdd Your Number
