Associated Numbers
17276 17561N 17561R 243-94104 4609150 830.541.103 91-27-3166 91-27-3166N M001T78681 M001T78681ZC M1T78681 M1T78681ZC S-8713 S1168M STR71150 UD12415SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 232 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Center - Center (O.2) | 71 mm |
Mount Hole Center - Center (O.3) | 67 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 10.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | Concorde 2.7 | 01.1998-12.2002 | |
CHRYSLER | Interpid 2.7 | 01.1995-12.2002 | |
CHRYSLER | Sebring 2.5 V6 | 01.1995-12.2000 | |
DODGE | Avenger 2.5 V6 | 01.1995-12.2000 | |
PLYMOUTH | Prowler 3.5 V6 | 01.1999- |
Reference Information
243-94104 17276 STR5312 4609150 UD12415S M1T78681ZC STRW192 M001T78681ZC S-8713 M001T78681 S1168M 17561R 17561N STR71150 M1T78681 91-27-3166 830.541.103 91-27-3166NVideo/Publications
17276 17561N 17561R 243-94104 4609150 830.541.103 91-27-3166 91-27-3166N M001T78681 M001T78681ZC M1T78681 M1T78681ZC S-8713 S1168M STR71150 STRW192 UD12415SAdd Your Number
