Associated Numbers
130-80113 151.512.133 19833N 20437156BN 243-25212 254515 6035651 CST35651 CST35651AS CST35651ES CST35651GS CST35651OS CST35651RS DRS0426 M008T60271 M8T60271 S-80122 UD12416SSpecifications
Kilowatt | 5 kW |
Length (L.1) | 286 mm |
Mount Hole Center - Center (O.1) | 145 mm |
Mount Hole Center - Center (O.2) | 105 mm |
Mount Hole Center - Center (O.3) | 105 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 23 mm |
Rotation | CW |
Spigot Diameter (A) | 100 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KOBELCO | SK210 IV | 01.1995- | |
MITSUBISHI | Engine | [4D31] | 01.1995-12.2005 |
MITSUBISHI | Engine | [4D32] | 01.1995-12.2005 |
Reference Information
19833N 243-25212 M008T80171 130-80113 M008T60271A CST35651ES CST35651GS CST35651AS 6035651 ME049186 CST35651OS M8T60271A CST35651 MAV376120 S-80122 CST35651RS UD12416S 20437156BN M008T60271 DRS0426 STR5265 M8T60271 STRL872 254515 151.512.133Video/Publications
130-80113 151.512.133 19833N 20437156BN 243-25212 254515 6035651 CST35651 CST35651AS CST35651ES CST35651GS CST35651OS CST35651RS DRS0426 M008T60271 M8T60271 MAV376120 S-80122 STRL872 UD12416SAdd Your Number
