Associated Numbers
19136N 91-27-3488 M000T23971 M000T23971ZC M0T23971 M0T23971ZC S-80280 UD13787SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 192 mm |
Mount Hole Center - Center (O.1) | 23.5 mm |
Mount Hole Center - Center (O.2) | 83.5 mm |
Mount Hole Center - Center (O.3) | 97.5 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
Mount Hole Diameter (C.3) | 11.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 30 mm |
Rotation | CW |
Spigot Diameter (A) | 68 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BUICK | Allure 3.0 | 01.2010-12.2010 | |
BUICK | Allure 3.6 | 01.2007-12.2010 | |
BUICK | Enclave 3.6 | 01.2009-12.2015 | |
BUICK | LaCrosse 3.0 | 01.2010-12.2010 | |
BUICK | LaCrosse 3.6 | 01.2007-12.2015 | |
BUICK | Rendezvous 3.6 | 01.2006-12.2006 | |
CADILLAC | ATS 3.6 | 01.2013-12.2015 | |
CADILLAC | CTS 2.8 | 01.2005-12.2007 | |
CADILLAC | CTS 3.0 | 01.2010-12.2014 | |
CADILLAC | CTS 3.6 | 01.2006-12.2013 | |
CADILLAC | CTS 3.6 | 01.2014-12.2015 | |
CADILLAC | SRX 3.0 | 01.2010-12.2011 | |
CADILLAC | SRX 3.6 | 01.2006-12.2015 | |
CADILLAC | STS 3.6 | 01.2006-12.2011 | |
CADILLAC | XTS 3.6 | 01.2013-12.2015 | |
CHEVROLET | Camaro 3.6 | 01.2010-12.2015 | |
CHEVROLET | Captiva 3.0 | 01.2011-12.2014 | |
CHEVROLET | Colorado 3.6 | 01.2013-12.2015 | |
CHEVROLET | Equinox 3.0 | 01.2010-12.2012 | |
CHEVROLET | Equinox 3.6 | 01.2008-12.2015 | |
CHEVROLET | Impala 3.6 | 01.2012-12.2015 | |
CHEVROLET | Impala Limited 3.6 | 01.2014-12.2015 | |
CHEVROLET | Malibu 3.6 | 01.2008-12.2012 | |
CHEVROLET | Traverse 3.6 | 01.2009-12.2015 | |
GMC | Acadia 3.6 | 01.2007-12.2015 | |
GMC | Canyon 3.6 | 01.2015-12.2015 | |
GMC | Terrain 3.0 | 01.2010-12.2012 | |
GMC | Terrain 3.6 | 01.2013-12.2015 | |
PONTIAC | G6 3.6 | 01.2007-12.2009 | |
PONTIAC | Torrent 3.6 | 01.2008-12.2009 | |
SAAB | 9-4X 3.0 | 01.2011-12.2011 | |
SATURN | Aura 3.6 | 01.2007-12.2009 | |
SATURN | Outlook 3.6 | 01.2007-12.2007 | |
SATURN | Outlook 3.6 | 01.2008-12.2010 | |
SATURN | Vue 3.6 | 01.2008-12.2010 | |
SUZUKI | XL-7 3.6 | 01.2007-12.2009 |
Reference Information
M0T23971ZC M000T23971ZC S-80280 M0T23971 19136N 91-27-3488 STR5290 M000T23971 UD13787SVideo/Publications
19136N 91-27-3488 M000T23971 M000T23971ZC M0T23971 M0T23971ZC S-80280 UD13787SAdd Your Number
