Associated Numbers
255057 255057P M009T71979 M9T71979 STD0229 UD13984SSpecifications
Kilowatt | 7.3 kW |
Length (L.1) | 404 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Center - Center (O.2) | 126 mm |
Mount Hole Center - Center (O.3) | 126 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
Mount Hole Diameter (C.3) | 14 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FREIGHTLINER | Engine 8.3 | [ISC] | 01.1994- |
STERLING | Engine 8.3 | [ISC] | 01.1994- |
Reference Information
255057 M009T71979 255057P M9T71979 STD0229 UD13984SVideo/Publications
255057 255057P M009T71979 M9T71979 STD0229 UD13984SAdd Your Number
