Associated Numbers
11470 130-20134 150.502.092 16720 20318 20500884 6035237 66925210 88212605 91-27-3431 9506 CST35237 CST35237AS CST35237ES CST35237GS CST35237OS CST35237RS DRS3046 JS318 M002T53081 M002T53082 M002T53083 M002T53085 M002T53086 M002T53281 M002T53282 M2T53081 M2T53082 M2T53083 M2T53085 M2T53086 M2T53281 M2T53282 MD023746 MD023782 MD027381 MD027585 MD072585 MD085731 MD092674 MD162389 MITM2T53083 S-8068 S1120M S1226M STM0318 UD14283SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 219 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 17 mm |
Rotation | CW |
Spigot Diameter (A) | 77 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | Conquest 2.6 | 01.1987-12.1989 | |
DODGE | Challenger 2.6 | 01.1981-12.1983 | |
DODGE | Colt 2.0 | 01.1984-12.1986 | |
DODGE | D50 2.0 | 01.1981-12.1982 | |
DODGE | D50 2.6 | 01.1981-12.1982 | |
HYUNDAI | Stellar 2.0 | 01.1987-12.1989 | |
MITSUBISHI | Cordia 2.0 | 01.1984-12.1985 | |
MITSUBISHI | Galant 2.4 | 01.1985-12.1996 | |
MITSUBISHI | Montero 2.6 | 01.1984-12.1986 | |
MITSUBISHI | Pickup 2.0 | 01.1983-12.1984 | |
MITSUBISHI | Pickup 2.6 | 01.1983-12.1984 | |
MITSUBISHI | Starion 2.6 | 01.1984-12.1989 | |
MITSUBISHI | Tredia 2.0 | 01.1984-12.1986 | |
PLYMOUTH | Arrow Pickup 2.0 | 01.1981-12.1983 | |
PLYMOUTH | Arrow Pickup 2.6 | 01.1981-12.1983 | |
PLYMOUTH | Sapporo 2.6 | 01.1981-12.1983 |
Reference Information
MD092674 CST35237OS JS318 M002T53082 M002T53081 M002T53282 M002T53083 M002T53281 MD027381 20500884 CST35237GS M002T53080 MD027585 MD023782 M002T52382 M002T52381 6035237 DRS3046 MD023746 MTC126 CST35237RS 11470 MD085731 003-C104 3C126 M2T52382 M2T52381 CST35237AS M2T53080 88212605 M2T53282 M2T53083 M2T53281 M2T53082 M2T53081 MD072585 9506 S1226M STM0318 16720 91-27-3431 CST35237 S-8068 UD14283S M2T53086 20318 M2T53085 CST35237ES MITM2T53083 130-20134 S1120M MTC104 150.502.092 STRF247 003-C126 3C104 MAV6050 MD162389 M002T53086 STR5000 M002T53085 66925210Video/Publications
003-C104 003-C126 11470 130-20134 150.502.092 16720 20318 20500884 3C104 3C126 6035237 66925210 88212605 91-27-3431 9506 CST35237 CST35237AS CST35237ES CST35237GS CST35237OS CST35237RS DRS3046 JS318 M002T53081 M002T53082 M002T53083 M002T53085 M002T53086 M002T53281 M002T53282 M2T53081 M2T53082 M2T53083 M2T53085 M2T53086 M2T53281 M2T53282 MAV6050 MD023746 MD023782 MD027381 MD027585 MD072585 MD085731 MD092674 MD162389 MITM2T53083 MTC104 MTC126 S-8068 S1120M S1226M STM0318 STRF247 UD14283SAdd Your Number
