Associated Numbers
130-90101 M009T50371 M009T50371ZC M9T50371 M9T50371ZC ME302485 S-80602 UD15039SSpecifications
Kilowatt | 5 kW |
Length (L.1) | 310 mm |
Mount Hole Center - Center (O.1) | 150.5 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 64 mm |
Rotation | CW |
Spigot Diameter (A) | 110 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Fuso FK 7.5 | ||
MITSUBISHI | Fuso FKS 7.5 |
Reference Information
M9T50371ZC M009T50371ZC M009T50371 130-90101 UD15039S M9T50371 S-80602 ME302485Video/Publications
130-90101 M009T50371 M009T50371ZC M9T50371 M9T50371ZC ME302485 S-80602 UD15039SAdd Your Number
