Associated Numbers
17943N 17943R 23300-EA000 31100-82Z00 31100-82Z01 91-27-3401 M000T88281 M000T88281ZC M000T88281ZCKD M0T88281 M0T88281ZC M0T88281ZCKD S-80336 STM8828 UD20403S
M000T88282 23300EA00A M0T88282
Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 202 mm |
Mount Hole Center - Center (O.1) | 97 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 18.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Frontier 2.5 | 01.2005-12.2015 | |
SUZUKI | Equator 2.5 | 01.2009-12.2018 |
Reference Information
STM8828 17943N STR5446 23300-EA00A M000T88281 M000T88281ZCKD 180.536.112.130 UD20403S 31100-82Z00 31100-82Z01 M0T88281 M0T88281ZC M000T88281ZC 91-27-3401 M0T88281ZCKD 17943R 23300-EA000 S-80336Video/Publications
17943N 17943R 23300-EA000 31100-82Z00 31100-82Z01 91-27-3401 M000T88281 M000T88281ZC M000T88281ZCKD M0T88281 M0T88281ZC M0T88281ZCKD S-80336 STM8828 UD20403SAdd Your Number
