Associated Numbers
17948N 20437922 243-14129 25-5168 254689 56044736AC 830.024.102 91-27-3477 DRS0883 DS1993 LRS04006 M000T23271ZC M0T23271 M0T23271ZC S-80583 STM4972 STM8972 UD20409SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 198 mm |
Mount Hole Center - Center (O.1) | 106 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 5.5 mm |
Rotation | CW |
Spigot Diameter (A) | 65 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Durango 5.7 V8 | [EZH] | 01.2011- |
DODGE | Ram 1500 5.7 V8 | [EZH] | 01.2008-12.2010 |
DODGE | Ram 2500 5.7 | [EZC] | 01.2009-12.2010 |
DODGE | Ram 2500 5.7 | [EZC] | 01.2013-12.2013 |
DODGE | Ram 2500 5.7 V8 | 01.2009- | |
DODGE | Ram 2500 5.7 V8 4x4 | 01.2009- | |
DODGE | Ram 3500 5.7 | [EZA] | 01.2008-12.2008 |
JEEP | Grand Cherokee 5.7 V8 4x4 | [EZH] | 01.2010- |
Reference Information
DS1993 M0T23271ZC M000T23271ZC S-80583 17948N M0T23271 LRS04006 254689 25-5168 243-14129 20437922 DRS0883 56044736AC STR5310 91-27-3477 UD20409S S5336S STM8972 830.024.102 STM4972 STRJ613 R6044736AC LRS4006Video/Publications
17948N 20437922 243-14129 25-5168 254689 56044736AC 830.024.102 91-27-3477 DRS0883 DS1993 LRS04006 LRS4006 M000T23271ZC M0T23271 M0T23271ZC S-80583 STM4972 STM8972 STRJ613 UD20409SAdd Your Number
