Associated Numbers
- ARROWHEAD SMT0298
- BOSCH SR6459X
- CHRYSLER MOTORS 04608800AA, 4608800AA, 4608800AD
- DENSO 280-4257
- J&N ELECTRICAL PRODUCTS 410-48169
- LESTER 17910
- LUCAS ELECTRIC LRS02717
- MITSUBISHI M000T22071, M0T21171, M0T21171ZC, M0T22071, M0T22071ZC
Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 225.5 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Center - Center (O.2) | 71 mm |
Mount Hole Center - Center (O.3) | 67 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 6 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | 300 C 2.7 | [2.7FX] | 09.2004-11.2012 |
CHRYSLER | 300 C 2.7 | [2.7FX] | 09.2004-12.2010 |
CHRYSLER | 300 C 2.7 | [EER] | 09.2004-11.2012 |
CHRYSLER | 300 C 2.7 | [EER] | 09.2004-12.2010 |
CHRYSLER | 300 C 2.7 | [EES] | 01.2007-11.2012 |
CHRYSLER | 300 C 2.7 | [EES] | 01.2007-12.2010 |
CHRYSLER | 300 C 3.5 | [EEG] | 09.2004-12.2010 |
CHRYSLER | 300 C 3.5 | [EGG] | 09.2004-11.2012 |
CHRYSLER | 300 C 3.5 | [EGG] | 09.2004-12.2010 |
CHRYSLER | 300 C 3.5 AWD | [EGG] | 09.2004-12.2010 |
Reference Information
S5341S 830.906.103 4608800AA 4608800AB M000T22071 LRS2717 STRS452 M008T88578 M000T32671 04608800AA M0T21171 M8T88578 STRS414 255079 CST35209AS LRS02717 04801651AA 25-4390 S-80366 4608800AC 3756 M0T32671 M000T21171 M000T32671ZC UD20394S M000T21171ZC 20437902 M0T21171ZC M0T22071 04608800AD 19025N M0T22071ZC M000T22071ZC M0T32671ZC STM4011 S12MH0746A2 6035209Video/Publications
04608800AA 04608800AD 04801651AA 19025N 20437902 25-4390 255079 3756 6035209 830.906.103 CST35209AS LRS02717 LRS2717 M000T21171 M000T21171ZC M000T22071 M000T22071ZC M000T32671ZC M008T88578 M0T21171 M0T21171ZC M0T22071 M0T22071ZC M0T32671 M0T32671ZC M8T88578 S-80366 STM4011 STRS414 STRS452 UD20394SAdd Your Number
