Associated Numbers
04727314AA 04727314AB 17911N 17911R 20437772 25-4104 255263 255263M 4727314AA 4727314AB 6035277 91-27-3403 AEY2432 CST35277 CST35277AS CST35277ES CST35277GS CST35277OS CST35277RS EAA-141434 K04727314AA K04727314AB LRS02432 M000T90481 M000T90481ZC M000T90482 M000T90482ZC M0T90481 M0T90481ZC M0T90482 M0T90482ZC S-80041 STM3008 STM9008 STR71318 UD20395SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 194.5 mm |
Mount Hole Center - Center (O.1) | 115.5 mm |
Mount Hole Center - Center (O.2) | 71.5 mm |
Mount Hole Center - Center (O.3) | 75 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 6.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | Grand Voyager 2.4i 16V | [EDO] | 01.2001-12.2007 |
CHRYSLER | Grand Voyager 2.4i 16V | [EDZ] | 01.2001-12.2007 |
CHRYSLER | Voyager 2.4i 16V | [EDO] | 01.2001-12.2007 |
CHRYSLER | Voyager 2.4i 16V | [EDZ] | 01.2001-12.2007 |
DODGE | Caravan 2.4 | [EDZ] | 01.2001-12.2007 |
Reference Information
S12MH0752 STRF478 CGB-54104 17911N DS1602 M000T90481 M000T90482 255263 UD20395S CST35277GS 20437772OE 4727314AB 830.591.103.770 M0T90482 S12MH0752A2 4727314AA LRS02432 3938 M0T90481 830.591.103.370 830.591.103.130 STR71318 STR5432 91-27-3403 LRS2432 DRS0492 M000T90482ZC STM3008 S5342S AEY2432 336519 6035277.1 25-4104 PRSF478 UD21252S 12320 255263M 04727314AA 04727314AB MAV372770 M0T90482ZC MT90481Video/Publications
STR71318 91-27-3403 17911N PRSF478 MAV372770 6035277.1 20437772OE 830.591.103.770 830.591.103.370 830.591.103.130 M0T90482ZC M000T90482ZC LRS2432 LRS02432 255263M STM3008 25-4104 12320 DS1602 DRS0492 4727314AB 04727314AB 3938 CST35277GS AEY2432 UD21252S UD20395S CGB-54104 STRF478Add Your Number
