Associated Numbers
23300-20P11 9559 M001T70685A M1T70685 M1T70685A STM9685 UD20461SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 207 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 8 qty |
Pinion at Rest (B) | 8.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Datsun 240 KGT 2.4 | [L24] | 09.1978-07.1981 |
NISSAN | Laurel 2.0 | [L20A] | 01.1981-01.1984 |
NISSAN | Laurel 2.0 | [L20A] | 03.1977-05.1983 |
NISSAN | Laurel 2.4 | [L24] | 01.1981-01.1984 |
NISSAN | Laurel 2.4 | [L24] | 09.1983-12.1985 |
NISSAN | Laurel 2.4 | [L24] | 12.1977-05.1983 |
Reference Information
STM9685 23300-20P11 M1T70685A M001T70685A 9559 M1T70685 UD20461SVideo/Publications
23300-20P11 9559 M001T70685A M1T70685 M1T70685A STM9685 UD20461SAdd Your Number
