Associated Numbers
140.547.112 17598N 20437743 25-4354 255633 3754 6035347 91-27-3475 AEY2682 CST35347 CST35347AS CST35347ES CST35347GS CST35347OS CST35347RS DRS0891 DS2001 J5213065 L538-18-400B LF8J-18-400A LF8J-18-400B LRS02682 M000T33271 M000T37271 M0T33271 M0T37271 S-80523 S-80525 STM7271 UD20367S m000t37571 m0t37571 - OE-L538-18-400B OE-L556-18-400 MITSUBISHI OE-M0T37271 OE-M0T37571 snj830 7060711 mxs2050 Light Duty 16383 Wilson References: Arrowhead SMT0438 Lester 17597 PIC Picture ID 1035172 41048299Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 210 mm |
Mount Hole Center - Center (O.1) | 97 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 22.5 mm |
Rotation | CW |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MAZDA | 3 2.0 | [LF-VDS] | 01.2009-12.2012 |
MAZDA | 3 2.0 | [PEY7] | 01.2011-12.2013 |
MAZDA | 3 2.3 Turbo | [L3KG] | 01.2009- |
MAZDA | 3 2.3 Turbo | [L3-VDT] | 01.2009- |
MAZDA | 3 2.5 | [L5-VE] | 01.2009-12.2014 |
MAZDA | 5 2.0 | [PE-VPS] | 01.2014- |
MAZDA | 6 2.0 MZR | [LF17] | 01.2010- |
MAZDA | 6 2.5 MZR | [L5-VE] | 01.2010- |
MAZDA | CX-7 2.3 MZR DiSi Turbo | [L3KG] | 01.2011- |
MAZDA | CX-7 2.3 MZR DiSi Turbo | [L3-VDT] | 01.2011- |
MAZDA | CX-7 2.5 MZR | [L5-VE] | 01.2009-12.2013 |
Reference Information
AEY2682 L538-18-400B 255633 25-4354 STM7271 LF8J-18-400A CST35347OS LF8J-18-400B 20437743 M000T33271 UD20367S DRS0891 M000T37271 3754 J5213065 J5213060 17598N CST35347GS S-80525 CST35347ES S-80523 CST35347 CST35347AS 140.547.112 CST35347RS M0T37271 LRS02682 M0T33271 6035347 LRS2682 DS2001 91-27-3475 STRE488 M0T37571Video/Publications
140.547.112 17598N 20437743 25-4354 255633 3754 6035347 91-27-3475 AEY2682 CST35347 CST35347AS CST35347ES CST35347GS CST35347OS CST35347RS DRS0891 DS2001 J5213060 J5213065 L538-18-400B LF8J-18-400A LF8J-18-400B LRS02682 LRS2682 M000T33271 M000T37271 M0T33271 M0T37271 S-80523 S-80525 STM7271 STRE488 UD20367SAdd Your Number
