Associated Numbers
17874N 17874R 25-5309 255680 56041914AC 830.953.112 91-27-3376 LRS04146 M00T20272 M00T20272ZC M0T20272 M0T20272ZC S-80070 STM2272 UD20388SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 198 mm |
Mount Hole Center - Center (O.1) | 106 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 6 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JEEP | Wrangler 4.0 TJ | [ERH] | 01.2003-12.2008 |
Reference Information
17874N M000T20272 MT20272ZC MAV373950A 255680 25-5309 S-80070 6035395 STR5178 M000T20272ZC MT20272 20437593BN 830.953.112 56041914AC M0T20272 M0T20272ZC M00T20272 M00T20272ZC STRJ076 LRS04146 STM2272 UD20388S CST35395AS LRS4146 17874R 91-27-3376Video/Publications
17874N 17874R 25-5309 255680 56041914AC 830.953.112 91-27-3376 LRS04146 LRS4146 M00T20272 M00T20272ZC M0T20272 M0T20272ZC S-80070 STM2272 STRJ076 UD20388SAdd Your Number
