Associated Numbers
17932N 17932R 243-17117 256004 56029274AA 830.957.102 91-27-3392 M000T21271 M000T21271ZC M000T21271ZCKD M0T21271 M0T21271ZC M0T21271ZCKD S-80342 STM4871 UD20399SSpecifications
Kilowatt | 1.7 kW |
Length (L.1) | 223 mm |
Mount Hole Center - Center (O.1) | 97.5 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 27.5 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Ram 1500 5.7 | 01.2005-12.2008 | |
DODGE | Ram 2500 5.7 | 01.2005-12.2008 | |
DODGE | Ram 3500 5.7 | 01.2005-12.2008 | |
DODGE | Ram 4000 5.7 | 01.2002-12.2002 | |
DODGE | Ram 4000 5.7 | 01.2005-12.2005 |
Reference Information
91-27-3392 M000T21271 17932N 830.957.102 S-80342 STRF648 M000T21271ZCKD M0T21271 56029274AA M0T21271ZCKD 256004 UD20399S M0T21271ZC M000T21271ZC 243-17117 STM4871 17932RVideo/Publications
17932N 17932R 243-17117 256004 56029274AA 830.957.102 91-27-3392 M000T21271 M000T21271ZC M000T21271ZCKD M0T21271 M0T21271ZC M0T21271ZCKD S-80342 STM4871 STRF648 UD20399SAdd Your Number
