Associated Numbers
M0T39471 M0T39471ZC UD16508S CST35380AS S-80554 CJ5T11000BA STM1526 M000T39471 M000T39471ZC 590.919.113 20437083BN 130-00166 6035380.0 30280R 91-27-3532Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 192 mm |
Mount Hole Center - Center (O.1) | 68 mm |
Mount Hole Center - Center (O.2) | 106 mm |
Mount Hole Center - Center (O.3) | 83 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 76 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Escape 1.6 | 01.2013-12.2016 | |
FORD | Fusion 1.5 | 01.2014-12.2017 | |
FORD | Fusion 1.5 | 01.2018-12.2018 | |
FORD | Fusion 1.6 | 01.2013-12.2014 | |
FORD | Fusion 1.6 | 01.2014-12.2014 |
Reference Information
S5400S STM1526 CJ5T11000BA M000T39471ZC 30280R M0T39471ZC STR5416 6035380 UD16508S M0T39471 590.919.113 CST35380AS 130-00166 91-27-3532 M000T39471 S-80554 20437083BNVideo/Publications
130-00166 20437083BN 30280R 590.919.113 6035380.0 91-27-3532 CJ5T11000BA CST35380AS M000T39471 M000T39471ZC M0T39471 M0T39471ZC S-80554 STM1526 UD16508SAdd Your Number
