Associated Numbers
228000-1120 228000-1121 228000-1122 25-3360 254055 EAA-121583 LRS02188 STR30042Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 189 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TCM | Forklift | ||
TCM | Fork Lift |
Reference Information
128000-1110 128000-1111 254055 228000-1120 228000-1121 228000-1122 5040609 8970489671 8970489670 8970489673 8970489672 336272 130.544.092.050 25-3360 254055D STR30042 89704896711 128000-1102 190-20166 128000-1101 128000-1100 228000-1130 228000-1131 228000-1132 228000-1133 LRS02188 228080-2003 130.544.092 8941702052 228000-1983 228000-3920 S6031 228000-1984 8941702050 228000-1985 8941702051 228000-1986 228000-3921 8.97049E+11 STN7121 DSN2129 228000-1980 228000-1981 228000-1982 8970489651 8970489650 STR6241 STN4121 8970489652 MAV5000 89704896611 CGB-23051 228000-2284 228000-2283 228000-2000 228000-2286 228000-2285 228000-2002 228000-2001 228000-2003 8970489660 8970489662 8970489661 228000-2280 S12DE0536A2 228000-2282 228000-2281 LRS2188 8970489663Video/Publications
130.544.092 190-20166 228000-1120 228000-1121 228000-1122 25-3360 254055 8941702050 8941702051 8941702052 8970489650 8970489651 8970489652 8970489660 8970489661 89704896611 8970489662 897048966211 8970489663 8970489670 8970489671 89704896711 8970489672 897048967211 8970489673 CGB-23051 DSN2129 LRS02188 LRS2188 MAV5000 STN4121 STN7121 STR30042Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
