Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 331.99 including GST
NZ$ 288.69 excluding GST
or four payments of $83.00
with
Learn More
each
S6056
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
428000-7470Associated Numbers
0000051829380 0000051872564 0001137003 0001137004 0051829380 0051872564 115828 20432153OE 25-4178 254621B 254621D 254896 254896B 254896D 428000-7470 51829380 51872564 6040351 AEY2506 CST40351GS DENDSN975 DSN975 LRS02506Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 189 mm |
| Mount Hole Center - Center (O.1) | 71 mm |
| Mount Hole Center - Center (O.2) | 47 mm |
| Mount Hole Center - Center (O.3) | 94 mm |
| Mount Hole Diameter (C.1) | 8.50 mm |
| Mount Hole Diameter (C.2) | 8.50 mm |
| Mount Hole Diameter (C.3) | 8.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 20 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | 500 0.9 | [312 A2.000] | 09.2010- |
| FIAT | 500 0.9 | [312A2.000] | 09.2010- |
| FIAT | 500 C 0.9 | [312 A2.000] | 09.2010- |
| FIAT | 500 C 0.9 | [312A2.000] | 09.2010- |
| FIAT | 500L 0.9 | [199 B6.000] | 09.2012- |
| FIAT | 500L 0.9 | [199B6.000] | 09.2012- |
| FIAT | 500L 0.9 CNG | [312 A2.000] | 03.2013- |
| FIAT | 500L 0.9 CNG | [312A2.000] | 03.2013- |
| FIAT | Panda 0.9 | [312 A2.000] | 02.2012- |
| FIAT | Panda 0.9 | [312A2.000] | 02.2012- |
| FIAT | Panda 0.9 4x4 | [312 A2.000] | 09.2012- |
| FIAT | Panda 0.9 4x4 | [312A2.000] | 09.2012- |
| FIAT | Panda 0.9 CNG | [312 A2.000] | 07.2012- |
| FIAT | Panda 0.9 CNG | [312A2.000] | 07.2012- |
| FIAT | Punto 0.9 Bifuel | [312 A2.000] | 03.2012- |
| FIAT | Punto 0.9 Bifuel | [312A2.000] | 03.2012- |
| FIAT | Punto 0.9 Twinair Turbo | [312 A2.000] | 03.2012- |
| FIAT | Punto 0.9 Twinair Turbo | [312A2.000] | 03.2012- |
| LANCIA | Ypsilon 0.9 Twinair | [312 A2.000] | 05.2011- |
| LANCIA | Ypsilon 0.9 Twinair | [312A2.000] | 05.2011- |
Reference Information
| 0000051829380 | FIAT |
| 0000051872564 | FIAT |
| 0001137003 | BOSCH |
| 0001137004 | BOSCH |
| 0051829380 | FIAT |
| 0051872564 | FIAT |
| 115828 | CARGO |
| 116024 | CARGO |
| 20432153BN | REAL |
| 20432153OE | REAL |
| 220672 | ERA |
| 25-4178 | ELSTOCK |
| 254621B | KUHNER |
| 254621D | KUHNER |
| 254896 | KUHNER |
| 254896B | KUHNER |
| 254896D | KUHNER |
| 428000-7470 | DENSO |
| 51829380 | FIAT |
| 51872564 | FIAT |
| 51938439 | FIAT |
| 6040351 | SANDO |
| 6040351.0 | SANDO |
| 6040351.1 | SANDO |
| AEY2506 | AUTOELECTRO |
| CST40351AS | CASCO |
| CST40351GS | CASCO |
| DENDSN975 | WOODAUTO |
| DSN975 | DENSO |
| F032115828 | CARGO |
| F032116024 | CARGO |
| LRS02506 | LUCAS |
| LRS2506 | LUCAS |
| MAV423510A | SIOM |
| RNL428000-7470 | RNL |
| S12BH0665 | SIDAT |
| S12BH0665A2 | SIDAT |
| S12DE0462 | SIDAT |
| S12DE0462A2 | SIDAT |
| S6056 | AS-PL |
| STR6444 | ELECTROLOG |
| STRJ790 | 3EFFE |
| STX210300 | STARDAX |
| STX210300R | STARDAX |
Video/Publications
