Associated Numbers
028000-9040 128000-1560 128000-1561 19744N 20432823BN 255585 28100-56160 28100-56161 28100-89100 28100-89107 6040328 CST40328AS STR70215Specifications
Kilowatt | 2.5 kW |
Length (L.1) | 297 mm |
Mount Hole Center - Center (O.1) | 146 mm |
Mount Hole Diameter (C.1) | M14x1.5 mm |
Mount Hole Diameter (C.2) | M14x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 17 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Various Models |
Reference Information
LRS4217 19744N 28100-89107 28100-56160 28100-56161 STR6042 LRS04217 028000-9040 CST40328AS 20432823BN 28100-89100 128000-1561 STRE135 128000-1560 S6064 190.556.112.050 28100-56310 2280003070 PRSE135 STN3744 6040328 6TC-81800-80 25-5379 STR70215 255585 28100-56311 190.556.112.901 6TC-81800-00 88212588 STR-6067Video/Publications
028000-9040 128000-1560 128000-1561 19744N 20432823BN 255585 28100-56160 28100-56161 28100-56311 28100-89100 28100-89107 6040328 CST40328AS STR70215Add Your Number
