Associated Numbers
0210001460 0210003260 0210003651 186-35032 23300-95000 23300-95009 23300-95015 23300-95016 UD02112SSpecifications
Kilowatt | 4.5 kW |
Length (L.1) | 297 mm |
Mount Hole Center - Center (O.1) | 115 mm |
Mount Hole Center - Center (O.2) | 115 mm |
Mount Hole Center - Center (O.3) | 132 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
Mount Hole Diameter (C.3) | 14 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 37 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Engine | [NE6] | |
NISSAN | Engine | [NF6] |
Reference Information
23300-95000 186-35032 23300-95015 ALT421090 23300-95016 210003651 210001460 UD02112S 23300-95009 210003260 MAV5740 STRW140Video/Publications
0210001460 0210003260 0210003651 186-35032 23300-95000 23300-95009 23300-95015 23300-95016 ALT421090 MAV5740 STRW140 UD02112SAdd Your Number
