Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 524.73 including GST
NZ$ 456.29 excluding GST
or four payments of $131.18
with
Learn More
each
S6119
1
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
1280005090Associated Numbers
028000-9160 028000-9770 113214 128000-5090 128000-5091 128000-5300 128000-5301 17292 17292N 190.577.112 20432742BN 254274 28100-1561A 28100-1930A 28100-1931A 28100-1960A 28100-1961 28100-89106 50-831001562 50-831001961 6040247 CST40247AS STR6066 UD02115S AS-PL CARGO CASCO DENSO DENSOList HINO KUHNER LESTER MERCURY PSH REAL SANDO MAV422470 SIOM TOYOTA UNIPOINTList WAI / TRANSPO 015090 Andre Niermann 0280009160 Denso 0280009770 0280009771 0280009772 0280009774 0280009775 Cargo 12060989 EuroTec 1280005090 show 1280005091 1280005092 1280005300 1280005301 1280009770 Lester 190577112 281001561A Toyota 281001930A 281001931 Hino 281001961 2810089106 91295123 Wilson F042000067 Bosch Unipoint 70-8559 SXS9801Specifications
| Kilowatt | 2.50 kW |
| Length (L.1) | 298 mm |
| Mount Hole Center - Center (O.1) | 153 mm |
| Mount Hole Diameter (C.1) | 15.50 mm |
| Mount Hole Diameter (C.2) | M14x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 31 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HINO | FA14 3.8 | 01.1988- | |
| HINO | FA15 3.8 | 01.1988- | |
| HINO | FB14 3.8 | 01.1985- | |
| HINO | FB15 3.8 | 01.1988- |
Reference Information
| 028000-9160 | DENSO |
| 028000-9770 | DENSO |
| 113214 | CARGO |
| 128000-5090 | DENSO |
| 128000-5091 | DENSO |
| 128000-5300 | DENSO |
| 128000-5301 | DENSO |
| 17292 | LESTER |
| 17292N | WAI / TRANSPO |
| 190.577.112 | PSH |
| 190.577.112.510 | PSH |
| 20432742BN | REAL |
| 254274 | KUHNER |
| 28100-1561A | HINO |
| 28100-1930A | HINO |
| 28100-1931A | HINO |
| 28100-1960A | HINO |
| 28100-1961 | HINO |
| 28100-89106 | TOYOTA |
| 336262 | LOGISTIK |
| 50-831001562 | MERCURY |
| 50-831001961 | MERCURY |
| 6040247 | SANDO |
| CST40247AS | CASCO |
| F032113214 | CARGO |
| MAV422470 | SIOM |
| S131.070 | PSH |
| STR6066 | UNIPOINT |
| STR6492 | ELECTROLOG |
| UD02115S | AS-PL |
Video/Publications
