Associated Numbers
UD02119SSpecifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 298 mm |
| Mount Hole Center - Center (O.1) | 118 mm |
| Mount Hole Diameter (C.1) | 14 mm |
| Mount Hole Diameter (C.2) | 14 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 18 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
